Product image is representative; revision or series may vary. Contact us to request a specific version.
SP1402
The Control Techniques SP1402, an AC drive from the Unidrive SP series, operates efficiently across various specifications. It provides a power supply of 380 to 480 Volts AC, with a rated current capacity between 3 and 3.8 Amperes, suitable for various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for SP1402
| Manufacturer | Control Techniques |
|---|---|
| Product Type | AC Drive |
| Product Line | Unidrive SP |
| Part Number | SP1402 |
| Weight | 9.00 lbs (4.08 kg) |
| Input Frequency Range | 48 to 65 Hertz |
| Input Phase Type | 3-phase input |
| Rated Current | 3 to 3.8 Amperes |
| Rated Active Power | 1.1 to 1.5 kilowatt |
| Power Supply Voltage | 380 to 480 Volts AC |
| Output Frequency Range | 0 to 550 Hertz |
| Communication Protocol | RS-485 and Modbus RTU (Remote Terminal Unit) |
| Encoder Type | Incremental and absolute encoder |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Protection Class | IP20 |
| Braking Unit | Dynamic braking transistor |
| Storage Temperature | -40 to 70°C (in a non-condensing environment) |
| Horsepower Capacity | 1 to 2 horsepower |
| Mounting Method | Panel mount |
The SP1402 AC drive from Control Techniques is engineered for 3-phase systems, accommodating an input frequency range of 48 to 65 Hertz. This unit draws a rated current of 3 to 3.8 Amperes and spans an output frequency range of up to 550 Hertz, making it versatile for many applications. Operating under a power supply voltage of 380 to 480 Volts AC, it has a rated active power between 1.1 and 1.5 kilowatts. This drive is effective for those seeking horsepower capabilities between 1 and 2.
Equipped with communication protocols RS-485 and Modbus RTU, the SP1402 supports seamless integration into automated systems. The unit can accommodate incremental and absolute encoders, enhancing its adaptability for diverse control scenarios. Designed to operate in a non-condensing environment, it can withstand ambient temperatures ranging from 0 to 40°C and can be stored at temperatures from -40 to 70°C.
The SP1402 includes a dynamic braking transistor as part of its braking unit for robust operation. Its construction meets IP20 protection standards, making it suitable for many industrial environments. The installation method is panel mount, simplifying the integration process into existing systems.
