Allen Bradley 1336 Adjustable 1336-BR-SP2A

Product image is representative; revision or series may vary. Contact us to request a specific version.

1336-BR-SP2A

|
Need a Specific Revision?

The 1336-BR-SP2A is a rectifier bridge transistor designed by Allen Bradley offering compatibility with multiple voltage levels. This component can efficiently operate with drive voltages of 230 VAC, 460 VAC, and 575 VAC, making it a versatile choice for various applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 1336-BR-SP2A

ManufacturerAllen Bradley
Product TypeRectifier Bridge Transistor
Product Line1336 Adjustable
Part Number1336-BR-SP2A
Weight0.50 lbs (0.23 kg)
Drive Voltage Compatibility230 VAC, 460 VAC, and 575 VAC
Drive Frame CompatibilityFrame B
Drive Horsepower Compatibility7.5 to 15 Hp
Number of Units Required by Each Drive1 Unit
Drives CompatibilityPLUS, PLUS II, FORCE, IMPACT & REGEN Drives
Mounting MethodDrive Mount
Minimum Operating Temperature0 Degrees Celsius
Maximum Operating Temperature50 Degrees Celsius
Minimum Storage Temperature-40 Degrees Celsius
Maximum Storage Temperature85 Degrees Celsius
Operating Humidity5 to 95% (Non-Condensing)
View as PDF
Request a Repair

The Allen Bradley 1336-BR-SP2A serves as a rectifier bridge transistor that facilitates reliable power conversion for various drive systems. This model is engineered to be compatible with 230 VAC, 460 VAC, and 575 VAC, allowing for flexible integration with different electrical setups. It specifically fits within the Frame B category and is designed to work with horsepower ratings ranging from 7.5 to 15 HP.

When implementing this rectifier, only one unit is necessary for each drive, streamlining the installation process. The 1336-BR-SP2A has compatibility with a range of drives, including PLUS, PLUS II, FORCE, IMPACT, and REGEN series, further extending its utility across applications.

Mounting is efficiently achieved through a drive mount method. The operational temperature of the device is specified to function correctly within the range of 0 to 50 degrees Celsius, which ensures functionality in typical industrial settings. In terms of storage, the transistor withstands conditions between -40 degrees Celsius and 85 degrees Celsius. It is also designed to operate in humidity levels of 5 to 95%, as long as condensation is not present. Overall, the 1336-BR-SP2A rectifier bridge transistor represents a valuable component for enhancing drive reliability and efficiency.

Revision Part #Also known as
1336-BR-SP2A Ser A1336-BR-SP2A/A, Series A, Rev A
Don't see your particular revision? Contact us now.
