1336R-VB180-AA-HAP

Revisions: Ser A
Description: The Allen-Bradley 1336R-VB180-AA-HAP REGEN Line Regeneration Package is a Line Regenerative Option for the Allen-Bradley 1336 PLUS, PLUS II, IMPACT and FORCE AC drives, which removes energy from the common DC bus of an AC drive, back onto a 3-phase AC utility line. It has 2 operational modes (Regenerative DC Bus Supply, and the Regenerative Braking), and the package consists of a Converter (transforms 3-phase AC input source into a DC output source), and a Pre-charge Unit (which limits inrush current). The 1336R-VB180-AA-HAP has a 3-phase input line range of 380V AC to 480V AC at 50-60Hz, with an output current rating of 180A, and a power rating of 143.7kW (180.4HP). It has an input tolerance of +10% to -15% at 48 to 62Hz, with an Auxiliary voltage range of 90 to 115V AC (single-phase), and with a tolerance of ±10% at 48 to 62Hz. read more...
Available Now
Request a quote for 1336R-VB180-AA-HAP

Description: The Allen-Bradley 1336R-VB180-AA-HAP REGEN Line Regeneration Package is a Line Regenerative Option for the Allen-Bradley 1336 PLUS, PLUS II, IMPACT and FORCE AC drives, which removes energy from the common DC bus of an AC drive, back onto a 3-phase AC utility line. It has 2 operational modes (Regenerative DC Bus Supply, and the Regenerative Braking), and the package consists of a Converter (transforms 3-phase AC input source into a DC output source), and a Pre-charge Unit (which limits inrush current). The 1336R-VB180-AA-HAP has a 3-phase input line range of 380V AC to 480V AC at 50-60Hz, with an output current rating of 180A, and a power rating of 143.7kW (180.4HP). It has an input tolerance of +10% to -15% at 48 to 62Hz, with an Auxiliary voltage range of 90 to 115V AC (single-phase), and with a tolerance of ±10% at 48 to 62Hz. read more...
About | Products Specs

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1336R-VB180-AA-HAP.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 8 reviews

    Technical Specifications for 1336R-VB180-AA-HAP

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336R-VB180-AA-HAP
Product Line1336 REGEN
Voltage380-480V AC
Current Rating180.4 Amps
Enclosure TypeIP20 (NEMA 1)
Human Interface OptionsProgrammer Only
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336R-VB180-AA-HAP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336R-VB180-AA-HAP units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336R-VB180-AA-HAP
Product Line1336 REGEN
Voltage380-480V AC
Current Rating180.4 Amps
Enclosure TypeIP20 (NEMA 1)
Human Interface OptionsProgrammer Only
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336R-VB180-AA-HAP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336R-VB180-AA-HAP units instead of migration.

s

About 1336R-VB180-AA-HAP

The Allen-Bradley 1336R-VB180-AA-HAP REGEN Line Regeneration Package is a Line Regenerative Option for the Allen-Bradley 1336 PLUS, PLUS II, IMPACT and FORCE AC drives, which removes energy from the common DC bus of an AC drive, back onto a 3-phase AC utility line. It has 2 operational modes (Regenerative DC Bus Supply, and the Regenerative Braking), and the package consists of a Converter (transforms 3-phase AC input source into a DC output source), and a Pre-charge Unit (which limits inrush current). The 1336R-VB180-AA-HAP has a 3-phase input line range of 380V AC to 480V AC at 50-60Hz, with an output current rating of 180A, and a power rating of 143.7kW (180.4HP). It has an input tolerance of +10% to -15% at 48 to 62Hz, with an Auxiliary voltage range of 90 to 115V AC (single-phase), and with a tolerance of ±10% at 48 to 62Hz. It offers 850V DC and 520V DC BUS overvoltage and under voltage trips at 480V AC line input, and it also offers a factory designated +15% of nominal input AC overvoltage trip.





The 1336R-VB180-AA-HAP offers a Transient Line Protection of up to 6000V with 1500V peak control noise Logic immunity, and it is designed to ride through a 6ms power loss, without interruption. It has 4035W of maximum heat dissipation in the Regenerative DC Bus Supply mode, and 2879W of heat dissipation in the Regenerative Brake mode, and it is designed to operate at a maximum height of 1,000m without de-rating. The 1336R-VB180-AA-HAP has a programming (only) Human Interface Module (HIM) option with IP20 rated enclosure, used for programming and configuration, and it may require either 3% or 10% 1321 Line Reactor. It comes in a NEMA Type 1 (IP20) rated enclosure, and it has an operating temperature range of 32 to 104°F, with a storage range of -40 to 185°F at 5 to 95% non-condensing relative humidity range. The 1336R-VB180-AA-HAP is built to withstand a 15G operating shock for 11ms, and it is also built to withstand a 1G peak vibration. It weighs approximately 108.9KG, with a shipping volume of 381.5mm x 1240.0mm x 270.8mm, and it both UL and CSA Certified.

This content was written and compiled by DO Supply and should not be copied.

Technical Description of 1336R-VB180-AA-HAP

Allen-Bradley 1336 REGEN with 380-480V AC power, 180.4 Amps Current Rating, and IP20 (NEMA 1) Enclosure

Repair Services for 1336R-VB180-AA-HAP

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1336R-VB180-AA-HAP. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1336R-VB180-AA-HAP

Please refer to the manual for more information about the 1336R-VB180-AA-HAP such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1336R-VB180-AA-HAP Ser A
1336R-VB180-AA-HAP/A, Series A, Rev A Request Quote
Common misspellings:
  • l336R-VB180-AA-HAP
  • 1336R-V8180-AA-HAP
  • 1336R-VBl80-AA-HAP
  • 1336R-VB1b0-AA-HAP
  • 1336R-VB18o-AA-HAP
  • 1336RVB180AAHAP

Dimensions For 1336R-VB180-AA-HAP

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 1336R-VB180-AA-HAP

Resolutions For 1336R-VB180-AA-HAP

About

Technical Specifications for 1336R-VB180-AA-HAP

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336R-VB180-AA-HAP
Product Line1336 REGEN
Voltage380-480V AC
Current Rating180.4 Amps
Enclosure TypeIP20 (NEMA 1)
Human Interface OptionsProgrammer Only
Product Lifecycle Status*Discontinued/Obsolete
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336R-VB180-AA-HAP
Product Line1336 REGEN
Voltage380-480V AC
Current Rating180.4 Amps
Enclosure TypeIP20 (NEMA 1)
Human Interface OptionsProgrammer Only
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336R-VB180-AA-HAP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336R-VB180-AA-HAP units instead of migration.

About 1336R-VB180-AA-HAP

The Allen-Bradley 1336R-VB180-AA-HAP REGEN Line Regeneration Package is a Line Regenerative Option for the Allen-Bradley 1336 PLUS, PLUS II, IMPACT and FORCE AC drives, which removes energy from the common DC bus of an AC drive, back onto a 3-phase AC utility line. It has 2 operational modes (Regenerative DC Bus Supply, and the Regenerative Braking), and the package consists of a Converter (transforms 3-phase AC input source into a DC output source), and a Pre-charge Unit (which limits inrush current). The 1336R-VB180-AA-HAP has a 3-phase input line range of 380V AC to 480V AC at 50-60Hz, with an output current rating of 180A, and a power rating of 143.7kW (180.4HP). It has an input tolerance of +10% to -15% at 48 to 62Hz, with an Auxiliary voltage range of 90 to 115V AC (single-phase), and with a tolerance of ±10% at 48 to 62Hz. It offers 850V DC and 520V DC BUS overvoltage and under voltage trips at 480V AC line input, and it also offers a factory designated +15% of nominal input AC overvoltage trip.





The 1336R-VB180-AA-HAP offers a Transient Line Protection of up to 6000V with 1500V peak control noise Logic immunity, and it is designed to ride through a 6ms power loss, without interruption. It has 4035W of maximum heat dissipation in the Regenerative DC Bus Supply mode, and 2879W of heat dissipation in the Regenerative Brake mode, and it is designed to operate at a maximum height of 1,000m without de-rating. The 1336R-VB180-AA-HAP has a programming (only) Human Interface Module (HIM) option with IP20 rated enclosure, used for programming and configuration, and it may require either 3% or 10% 1321 Line Reactor. It comes in a NEMA Type 1 (IP20) rated enclosure, and it has an operating temperature range of 32 to 104°F, with a storage range of -40 to 185°F at 5 to 95% non-condensing relative humidity range. The 1336R-VB180-AA-HAP is built to withstand a 15G operating shock for 11ms, and it is also built to withstand a 1G peak vibration. It weighs approximately 108.9KG, with a shipping volume of 381.5mm x 1240.0mm x 270.8mm, and it both UL and CSA Certified.

This content was written and compiled by DO Supply and should not be copied.

Technical Description of 1336R-VB180-AA-HAP

Allen-Bradley 1336 REGEN with 380-480V AC power, 180.4 Amps Current Rating, and IP20 (NEMA 1) Enclosure
