1336-BDB-SP46D

Revisions: Ser A
Description: The 1336-BDB-SP46D is a PCB gate drive board from Allen-Bradley/Rockwell Automation. The drive board replaced the 1336-BDB-SP46A. The 1336-BDB-SP46D is a 1336STEF series with a Frame G type frame and it has a Horsepower rating of 600 Horsepower. To operate, the 1336-BDB-SP46D uses an AC power supply that has a rating of 460 Volts AC. read more...
