1336S-BRF05-AA-EN

Revisions: Ser A
Description: The 1336S-BRF05-AA-EN built by Allen-Bradley/Rockwell Automation is a 380-480 VAC drive. Additionally, it is a 1/2 horsepower drive and is a 0.37 kW unit. This 1336 Plus AC drive is a size A1 frame drive. This adjustable frequency drive is contained in an IP 20 (NEMA 1) enclosure. This VFD has an English module on the drive.
In Stock Ships Today
Request a quote for 1336S-BRF05-AA-EN

Description: The 1336S-BRF05-AA-EN built by Allen-Bradley/Rockwell Automation is a 380-480 VAC drive. Additionally, it is a 1/2 horsepower drive and is a 0.37 kW unit. This 1336 Plus AC drive is a size A1 frame drive. This adjustable frequency drive is contained in an IP 20 (NEMA 1) enclosure. This VFD has an English module on the drive.

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1336S-BRF05-AA-EN.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.9 with 8 reviews

    Technical Specifications for 1336S-BRF05-AA-EN

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336S-BRF05-AA-EN
Voltage380 to 480 Volts AC or 513 to 620 Volts DC
kW (Horsepower)0.37 (0.5)
Enclosure TypeIP20 (NEMA 1)
LanguageEnglish
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF05-AA-EN has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF05-AA-EN units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336S-BRF05-AA-EN
Voltage380 to 480 Volts AC or 513 to 620 Volts DC
kW (Horsepower)0.37 (0.5)
Enclosure TypeIP20 (NEMA 1)
LanguageEnglish
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF05-AA-EN has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF05-AA-EN units instead of migration.

s

About 1336S-BRF05-AA-EN

The 1336S-BRF05-AA-EN drive is a compact AC drive which belongs to the 1336 PLUS product range from Allen-Bradley. Motor control algorithms supported by 1336 PLUS drives include sensorless vector control with full tuning and the standard Volts per Hertz control with full customer capability. An English language module comes installed on the 1336S-BRF05-AA-EN drive. The 1336S-BRF05-AA-EN drive can operate at either 513 to 620 Volts DC or at 380 to 480 Volts AC. The drive draws 0.9 to 1 kVA and 0.9 to 1.1 kVA input power for the constant and variable torque modes respectively. The output power rating of the 1336S-BRF05-AA-EN drive is 0.37 kilowatts or 0.5 Horsepower. The input and output currents for constant torque operation are 1.3 and 1.1 Amps, respectively. The input and output currents for variable torque operation are 1.4 and 1.2 Amps, respectively. The total heat dissipated by an operating drive is 21 Watts.



AC input over-voltage and under-voltage thresholds are 570 and 280 Volts AC. The nominal bus voltage for the 1336S-BRF05-AA-EN drive is 648 Volts DC. The bus over-voltage and under-voltage trip thresholds are 810 and 400 Volts DC. The A1-frame 1336S-BRF05-AA-EN drive weighs 9.5 pounds. The dimensions of the NEMA Type 1 drive enclosure are 11.42 x 8.5 x 6.3 inches. The recommended minimum horizontal spacing between 2 adjacent drives is 4 inches and the minimum vertical spacing is 6 inches. These spacing recommendations are made by Allen-Bradley to help ensure that the ambient temperature around the drives stays within the recommended operating temperature range of 32 to 104 degrees Fahrenheit. The temperature range for drive storage is from -40 to 158 degrees Fahrenheit.



Technical Description of 1336S-BRF05-AA-EN

This 1336 PLUS Adjustable Frequency AC drive is a 380-480VAC or 513-620V DC unit with 0.37 (0.5) kilowatts(horsepower) and has a(n) IP 20 (NEMA 1) enclosure. This unit is in the English language.

Repair Services for 1336S-BRF05-AA-EN

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1336S-BRF05-AA-EN. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1336S-BRF05-AA-EN

Please refer to the manual for more information about the 1336S-BRF05-AA-EN such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1336S-BRF05-AA-EN Ser A
1336S-BRF05-AA-EN/A, Series A, Rev A Request Quote
