1336S-BRF50-AA-EN-L6

Revisions: Ser A Ser B Ser C Ser D
Description: Allen-Bradley 1336 PLUS Drive with 380-480V AC or 513-620V DC voltage, 5 horsepower rating and IP20 (NEMA 1) enclosure
Available Now
Request a quote for 1336S-BRF50-AA-EN-L6

Description:

Allen-Bradley 1336 PLUS Drive with 380-480V AC or 513-620V DC voltage, 5 horsepower rating and IP20 (NEMA 1) enclosure


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B Ser C Ser D

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1336S-BRF50-AA-EN-L6.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 3.5 with 6 reviews

    Technical Specifications for 1336S-BRF50-AA-EN-L6

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336S-BRF50-AA-EN-L6
Product Line1336 PLUS
Voltage380-480V AC or 513-620V DC
HP Rating5
Enclosure TypeIP20 (NEMA 1)
LanguageEnglish
Control Interface Options115V AC
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF50-AA-EN-L6 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF50-AA-EN-L6 units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336S-BRF50-AA-EN-L6
Product Line1336 PLUS
Voltage380-480V AC or 513-620V DC
HP Rating5
Enclosure TypeIP20 (NEMA 1)
LanguageEnglish
Control Interface Options115V AC
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF50-AA-EN-L6 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF50-AA-EN-L6 units instead of migration.

s

About 1336S-BRF50-AA-EN-L6

The Allen-Bradley 1336S-BRF50-AA-EN-L6 is a variable frequency AC drive. It belongs to the 1336 PLUS family of drives. The range of working input voltage for the 1336S-BRF50-AA-EN-L6 is from 380 to 480 Volts AC. The input frequency range is 48 to 62 Hertz. The output of this advanced drive carries a rating of 5 Horsepower and 3.7 kilowatts. This output rating is available with 3-phase input, and it derates to 50% with 1-phase input. A control interface option available on the 1336S-BRF50-AA-EN-L6 is rated at 115 Volts AC. Integrated HMI is not available on the drive. The 1336S-BRF50-AA-EN-L6 can operate in both constant and variable torque modes. The input specifications for constant torque are 10 Amps and 6.6 to 8 KVA. The output specifications for constant torque are 8.4 Amps and 6.7 KVA. The input specifications for variable torque are 10.7 Amps and 7 to 8.6 KVA. The output specifications for variable torque are 9 Amps and 7.2 KVA.



The 1336S-BRF50-AA-EN-L6 should be installed and serviced by trained personnel. All the ESD guidelines should be followed to prevent personnel injury and equipment damage. It is critically important that voltage on the bus capacitors should be allowed to discharge completely prior to the initiation of any service activity. The 1336S-BRF50-AA-EN-L6 is available in an IP20 rated (NEMA type 1) enclosure which measures 11.42 x 8.5 x 8.15 inches and weighs 6.71 kilograms. The drive requires an environment with 5 to 95% relative ambient humidity and a 0 to 50 degrees Celsius temperature range for optimal performance. The drive should be stored in an area with an ambient temperature in the -40 to 70 degrees Celsius range.



Repair Services for 1336S-BRF50-AA-EN-L6

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 1336S-BRF50-AA-EN-L6. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 1336S-BRF50-AA-EN-L6

Please refer to the manual for more information about the 1336S-BRF50-AA-EN-L6 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1336S-BRF50-AA-EN-L6 Ser A
1336S-BRF50-AA-EN-L6/A, Series A, Rev A Request Quote
1336S-BRF50-AA-EN-L6 Ser B
1336S-BRF50-AA-EN-L6/B, Series B, Rev B Request Quote
1336S-BRF50-AA-EN-L6 Ser C
1336S-BRF50-AA-EN-L6/C, Series C, Rev C Request Quote
1336S-BRF50-AA-EN-L6 Ser D
1336S-BRF50-AA-EN-L6/D, Series D, Rev D Request Quote
Common misspellings:
  • l336S-BRF50-AA-EN-L6
  • 1336S-8RF50-AA-EN-L6
  • 1336S-BRF5o-AA-EN-L6
  • 1336S-BRF50-AA-EN-16
  • 1336SBRF50AAENL6

Dimensions For 1336S-BRF50-AA-EN-L6
