1336S-BRF50-AA-EN5-L4 | Allen Bradley Drives 1336 PLUS Drives

1336S-BRF50-AA-EN5-L4

Rated 4.8 with 11 reviews

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

1336S-BRF50-AA-EN5-L4

Description: The 1336S-BRF50-AA-EN5-L4 AC drive with adjustable frequency is available through the 1336 PLUS product series introduced by Allen-Bradley/Rockwell Automation. The drive includes an optional control interface with TTL contact and an IP 20 (NEMA Type 1) rated enclosure. The input voltage of the drive is from 380 to 480 Volts AC and 513 to 620 Volts DC and the power rating is 3.7 kilowatts or 5 Horsepower.
Available Now
Request a quote for 1336S-BRF50-AA-EN5-L4

Description:

The 1336S-BRF50-AA-EN5-L4 AC drive with adjustable frequency is available through the 1336 PLUS product series introduced by Allen-Bradley/Rockwell Automation. The drive includes an optional control interface with TTL contact and an IP 20 (NEMA Type 1) rated enclosure. The input voltage of the drive is from 380 to 480 Volts AC and 513 to 620 Volts DC and the power rating is 3.7 kilowatts or 5 Horsepower.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1336S-BRF50-AA-EN5-L4.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.8 with 11 reviews

    Technical Specifications for 1336S-BRF50-AA-EN5-L4

BrandAllen-Bradley / Rockwell Automation
Series1336 PLUS Drives
Part Number1336S-BRF50-AA-EN5-L4
Voltage380 to 480 Volts AC or 513 to 620 Volts DC
Nominal HP rating3.7 kilowatts / 5 Horsepower
EnclosureIP 20 (NEMA Type 1)
LanguageEnglish/English V5.xx
Control interfaceTTL contact
AC input overvoltage/undervoltage trip570 / 280 Volts AC
Bus overvoltage/undervoltage trip810 / 400 Volts DC
Nominal bus voltage648 Volts DC
Efficiency97.5% at rated Amps, nominal line Volts
Input frequency tolerance48 to 62 Hertz
Ambient operating temperature0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit)
Storage temperature-40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit)
Shock15G peak for 11 milliseconds duration
Vibration0.006 inches (0.152 millimeters) displacement, 1G peak
CertificationsUL listed, CSA certified, CE marked
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF50-AA-EN5-L4 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF50-AA-EN5-L4 units instead of migration.

BrandAllen-Bradley / Rockwell Automation
Series1336 PLUS Drives
Part Number1336S-BRF50-AA-EN5-L4
Voltage380 to 480 Volts AC or 513 to 620 Volts DC
Nominal HP rating3.7 kilowatts / 5 Horsepower
EnclosureIP 20 (NEMA Type 1)
LanguageEnglish/English V5.xx
Control interfaceTTL contact
AC input overvoltage/undervoltage trip570 / 280 Volts AC
Bus overvoltage/undervoltage trip810 / 400 Volts DC
Nominal bus voltage648 Volts DC
Efficiency97.5% at rated Amps, nominal line Volts
Input frequency tolerance48 to 62 Hertz
Ambient operating temperature0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit)
Storage temperature-40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit)
Shock15G peak for 11 milliseconds duration
Vibration0.006 inches (0.152 millimeters) displacement, 1G peak
CertificationsUL listed, CSA certified, CE marked
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BRF50-AA-EN5-L4 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BRF50-AA-EN5-L4 units instead of migration.

s

About 1336S-BRF50-AA-EN5-L4

The 1336S-BRF50-AA-EN5-L4 industrial drive by Allen-Bradley is used for 3-phase systems that are constructed from high-quality and reliable components. The drive is easy to maintain and install, and it includes crucial protective features that provide safety. The protective features include a power ride-thru of 15 milliseconds at a full load, a phase-to-ground ground fault trip, and a phase-to-phase short circuit trip. The drive is enclosed in a NEMA Type 1 (IP 20) rated enclosure and it features English (version 5.xx) as its default language. The series offers support for other languages since these drives are used on a worldwide scale. Also, the drive complies with directives for electromagnetic compatibility (EMC), emissions, and immunity. The 1336S-BRF50-AA-EN5-L4 drive has a power output rating of 3.7 kilowatts or 5 Horsepower and a supported voltage range of 380 to 480 Volts AC or 513 to 620 Volts DC.







The 1336S-BRF50-AA-EN5-L4 drive is equipped with control interface functionality that is necessary for some applications. Since the product series offers several variants, this control interface is a variant with a TTL contact. The drive is built on microprocessor technology and it provides selectable motor control that includes sensorless vector control (full tuning) and the standard Volts per Hertz control (full custom).  The 1336S-BRF50-AA-EN5-L4 drive has an A3 type of frame and dimensions that include 215.9 millimeters (8.5 inches) in width, 290 millimeters (11.4 inches) in height, and 207 millimeters (8.1 inches) in depth. In addition to that, the drive has a shipping weight of 6.71 kilograms (14.8 pounds). The drive supports ambient operating temperatures from 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit) and storage temperatures from -40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit).



Repair Services for 1336S-BRF50-AA-EN5-L4

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1336S-BRF50-AA-EN5-L4. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.
