1336S-BX060-AN-EN3

Revisions: Ser A Ser B Ser C Ser D
Description: The 1336S-BX060-AN-EN3 drive is made by Allen-Bradley/Rockwell Automation and it is part of their 1336 PLUS product series. This industrial component has an output power rating and 45 killowatts or 60 Horsepower. The drive includes an IP 00 (Open) enclosure and a version 4.xx English language module.
In Stock Ships Today
Request a quote for 1336S-BX060-AN-EN3

Description:

The 1336S-BX060-AN-EN3 drive is made by Allen-Bradley/Rockwell Automation and it is part of their 1336 PLUS product series. This industrial component has an output power rating and 45 killowatts or 60 Horsepower. The drive includes an IP 00 (Open) enclosure and a version 4.xx English language module.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B Ser C Ser D

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1336S-BX060-AN-EN3.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.5 with 10 reviews

    Technical Specifications for 1336S-BX060-AN-EN3

BrandAllen-Bradley / Rockwell Automation
Series1336 PLUS Drives
Part Number1336S-BX060-AN-EN3
VoltageSpecial rating
Nominal HP rating45 kilowatts / 60 Horsepower
EnclosureIP 00 (Open)
LanguageEnglish/English V3.xx
OptionsNone
Efficiency97.5% at rated Amps, nominal line Volts
Input frequency tolerance48 to 62 Hertz
Ambient operating temperature0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit)
Storage temperature-40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit)
Shock15G peak for 11 milliseconds duration
Vibration0.006 inches (0.152 millimeters) displacement, 1G peak
CertificationsUL listed, CSA certified, CE marked
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BX060-AN-EN3 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BX060-AN-EN3 units instead of migration.

BrandAllen-Bradley / Rockwell Automation
Series1336 PLUS Drives
Part Number1336S-BX060-AN-EN3
VoltageSpecial rating
Nominal HP rating45 kilowatts / 60 Horsepower
EnclosureIP 00 (Open)
LanguageEnglish/English V3.xx
OptionsNone
Efficiency97.5% at rated Amps, nominal line Volts
Input frequency tolerance48 to 62 Hertz
Ambient operating temperature0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit)
Storage temperature-40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit)
Shock15G peak for 11 milliseconds duration
Vibration0.006 inches (0.152 millimeters) displacement, 1G peak
CertificationsUL listed, CSA certified, CE marked
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336S-BX060-AN-EN3 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336S-BX060-AN-EN3 units instead of migration.

s

About 1336S-BX060-AN-EN3

The 1336S-BX060-AN-EN3 drive has adjustable frequency and it features sensorless vector control and microprocessor technologies. Also, the drive provides standard Volts per Hertz control that can be completely customized. The drive is part of the 1336 PLUS series and it has an open type of enclosure that supports ambient temperatures of up to 50 degrees Celsius (122 degrees Fahrenheit). The drive is made for standard industrial operating conditions and it is CSA certified and CE marked. The 1336S-BX060-AN-EN3 drive can be used at altitudes of up to 1000 meters (3300 feet) above sea level without de-rating and in locations with relative humidity levels from 5 to 95% (non-condensing). In addition to that, the drive has a moderate resistance to vibration and shock. There are convenient and easily available spare parts and the drive only needs easy maintenance procedures that reduce costs and save time. The drive is delivered with a manual that helps new operators to learn everything about the drive’s functions.







The 1336S-BX060-AN-EN3 drive has a special rating for input voltage and its output power rating is 45 kilowatts and 60 Horsepower. The 1336 PLUS product series offers custom options for communication, programming interface, and control features. All of these options come in several variants in order to meet different requirements. However, the 1336S-BX060-AN-EN3 drive comes with default functions and it does not include custom options unless they are ordered separately. The heat sink thermistor of the drive is monitored by a microprocessor over-temperature trip and its line transients are up to 6000 Volts peak per the IEEE 062.41-1991 standard. The logic control ride-thru of the drive is 0.5 seconds/2 seconds (minimum/typical).



Repair Services for 1336S-BX060-AN-EN3

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1336S-BX060-AN-EN3. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1336S-BX060-AN-EN3

Please refer to the manual for more information about the 1336S-BX060-AN-EN3 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1336S-BX060-AN-EN3 Ser A
1336S-BX060-AN-EN3/A, Series A, Rev A Request Quote
1336S-BX060-AN-EN3 Ser B
1336S-BX060-AN-EN3/B, Series B, Rev B Request Quote
1336S-BX060-AN-EN3 Ser C
1336S-BX060-AN-EN3/C, Series C, Rev C Request Quote
1336S-BX060-AN-EN3 Ser D
1336S-BX060-AN-EN3/D, Series D, Rev D Request Quote
