The 40 Horsepower 1336F-BX040-AA-EN-HCS1-L6 drive from Allen-Bradley is an advanced microprocessor-controlled AC drive. It is part of the Allen-Bradley 1336 PLUS II series of compact AC drives. At a rated input of 480 Volts AC (3-phase, 47 to 63 Hertz), for both constant and variable torque modes, the 1336F-BX040-AA-EN-HCS1-L6 delivers 60 Horsepower and 59 Amps at the output. The input current rating of the drive is 61 Amps. The range for voltage at the output is from 0 to the rated motor voltage. The sine-coded PWM control method with configurable carrier frequencies is available on the drive. The integrated I/O on the drive support 115 Volts AC. The drive also features an integrated programmer/controller with an analog potentiometer with upload and download capabilities. The language supported by the onboard programmer is English.

Available in an IP20-rated Frame C enclosure measuring 27.6 x 11.8 x 8.8 inches, the 1336F-BX040-AA-EN-HCS1-L6 drive weighs 38.6 kilograms. A total of 1108 Watts are dissipated as heat during drive operation. The total heat dissipation includes 933 Watts which are dissipated by the heatsink and 175 Watts dissipated by the drive. The heatsink temperature is monitored by an onboard microprocessor which is programmed to trip the drive when the overtemperature threshold is exceeded. The 1336F-BX040-AA-EN-HCS1-L6 is designed for an ambient operating temperature and a relative humidity ranging from 32 to 104 degrees Fahrenheit and 5 to 95%, respectively. The shock rating for the 1336F-BX040-AA-EN-HCS1-L6 is 15 G peak for 11 milliseconds. The vibration rating for the drive is 0.006 inches of displacement at 1 G peak.
