2097-V32PR4-LM | Allen Bradley Drives Kinetix 350

2097-V32PR4-LM

Rated 4.4 with 8 reviews

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.


credit cards accepted
better business bureau

2097-V32PR4-LM

Revisions: Ser A
Description: The 2097-V32PR4-LM is a Kinetix 350 Ethernet I/P servo drive. This is a single-axis servo drive with an AC input voltage range of 80-264 VAC rms with nominal value of 230 VAC, 1-phase along an input frequency of 48-62 Hz. This drive has continuous output current and power of 8 A and 1.70 kW respectively. This servo drive comes with an integrated AC filter and Safe Torque Off (STO) feature.
Call
Request a quote for 2097-V32PR4-LM

Description: The 2097-V32PR4-LM is a Kinetix 350 Ethernet I/P servo drive. This is a single-axis servo drive with an AC input voltage range of 80-264 VAC rms with nominal value of 230 VAC, 1-phase along an input frequency of 48-62 Hz. This drive has continuous output current and power of 8 A and 1.70 kW respectively. This servo drive comes with an integrated AC filter and Safe Torque Off (STO) feature.

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 2097-V32PR4-LM.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 8 reviews

    Technical Specifications for 2097-V32PR4-LM

ManufacturerRockwell Automation
BrandAllen-Bradley
Manufacturer Rockwell Automation
Brand Allen-Bradley
Product BulletinKinetix 300
Product Description Kinetix 350 Ethernet I/P Single Drives
Input Frequency 48…62 Hz
Main AC input current, Nom (rms)15.0 A
Main AC input current, Nom (0-pk)2.3 A
Integrated AC line filterYes
Control power back-up input voltage20…26V DC
Control power back-up input current, nominal500 mA
Control power back-up input current, max. inrush30 A
Continuous Output Current (0-peak)11.3 Amperes
ListingThese specifications were compiled by DO Supply Inc (D O Supply).
Continuous output current (rms) 8.0 A
Weight4.9 lbs (2.2 kg)
Dimensions9.37 x 9.04 x 3.8 in (238 x 229.6 x 96.5 mm)
Safe Torque-OffYes
Part Number/Catalog No.2097-V32PR4-LM
Power Rating1.7 kWatts
Input Voltage80-264 rms single-phase (230V nom)
Integrated AC (EMC) Line FilterYes
120 Volts Doubler ModeNo
Continuous output current (0-pk)11.3 A
Peak output current (rms)24.0 A
Peak output current (0-pk)33.9 A
Continuous power output 1.70 kW
ManufacturerRockwell Automation
BrandAllen-Bradley
Manufacturer Rockwell Automation
Brand Allen-Bradley
Product BulletinKinetix 300
Product Description Kinetix 350 Ethernet I/P Single Drives
Input Frequency 48…62 Hz
Main AC input current, Nom (rms)15.0 A
Main AC input current, Nom (0-pk)2.3 A
Integrated AC line filterYes
Control power back-up input voltage20…26V DC
Control power back-up input current, nominal500 mA
Control power back-up input current, max. inrush30 A
Continuous Output Current (0-peak)11.3 Amperes
Continuous output current (rms) 8.0 A
Weight4.9 lbs (2.2 kg)
Dimensions9.37 x 9.04 x 3.8 in (238 x 229.6 x 96.5 mm)
Safe Torque-OffYes
Part Number/Catalog No.2097-V32PR4-LM
Power Rating1.7 kWatts
Input Voltage80-264 rms single-phase (230V nom)
Integrated AC (EMC) Line FilterYes
120 Volts Doubler ModeNo
Continuous output current (0-pk)11.3 A
Peak output current (rms)24.0 A
Peak output current (0-pk)33.9 A
Continuous power output 1.70 kW
s

About 2097-V32PR4-LM

The Allen-Bradley 2097-V32PR4-LM is an Ethernet I/P enabled servo drive. This drive is part of the Kinetix 350 motion control system, which are intelligent and highly configurable drives. With Ethernet I/P capability, this drive supports integration to the Logix controller platform specifically, CompactLogix and ControlLogix controllers, via premiere integration method. This integration method allows drive parameters to be accessed by the mentioned controllers for direct manipulation and inclusion to the user program. Other configuration methods are still supported by this drive.

The 2097-V32PR4-LM is compatible operates when supplied with an voltage range of 80-264 VAC, 1-phase with nominal value of 230 VAC along an input frequency of 48-62 Hz. It has motor applicable output parameters such as continuous output current (rms) of 8.0 Amperes and Continuous output current (0-pk) of 11.3 Amperes. The output power ratings include 1.70 kW continuous output @ 240 VAC or 120 VAC when set at voltage double mode. This drive is capable of continuous monitoring of DC bus voltage and comes with overvoltage protection which sets on when 430 VDC bus voltage is reached. It also has a short-circuit current rating of 100,000 A (rms), symmetrical.

The 2097-V32PR4-LM notable integrated features include an AC line filter and Safe-Torque Off (STO) functionality which is activated when the safety circuit is tripped. This safety feature prevents automatic restart, preventing untoward incidents, related to safety, from occurring.

The 2097-V32PR4-LM has a power dissipation of 67 Watts. During installation, maintain 25.0 mm top and bottom clearance and 3.0 mm side clearances. These clearances are the minimum requirement, which may also vary depending on the installed accessories.

The 2097-V32PR4-LM drive is a single axis Kinetix 350 Ethernet I/P Servo drive. Allen-Bradley is the manufacturer of the 2097-V32PR4-LM with continuous output power rating of 1.7 kWatts, a Continuous Output Current of 8.0 Amperes and an Input Voltage of 240 Volts (AC), 1 Phase. The drive is comprised of many specifications that greatly simplify its operational user interface.

The 2097-V32PR4-LM comes with numerous power specs which are an economical choice and can provide efficient power solutions. For this reason, the series is ideal for CompactLogix and ControlLogix controllers that are designed to use EtherNet/IP networks. It comes with cost-effective and high-performance features that allow integration with MP-Series and servo motors from TL series and actuators. The drive is designed to provide the user with a comprehensive and integrated power solution that guarantees the unmatched success of an operation. The Allen-Bradley 2097-V32PR4-LM offers the best power solutions to help maximize production; it uses innovative specs to ensure optimal system configuration, ensuring top efficiencies from engineering straight to commissioning.

FAQ for 2097-V32PR4-LM

1. What is the output power and current of the 2097-V32PR4-LM?


The 2097-V32PR4-LM’s output parameters include continuous output current of 8.0 Amperes and Continuous output current (0-pk) of 11.3 Amperes while the output power rating is 1.70 kW continuous output @ 240 VAC or 120 VAC when set at voltage double mode.

2. What is the input voltage supply requirement of the 2097-V32PR4-LM?


The 2097-V32PR4-LM is powered by an input supply voltage range of 80-264 VAC rms with nominal value of 230 VAC, 1-phase.

3. Does the 2097-V32PR4-LM integration to Logix controllers?


Yes. The 2097-V32PR4-LM support integration to logix controllers via premiere integration.

Technical Description of 2097-V32PR4-LM

The Allen-Bradley 2097-V32PR4-LM exhibits a 1.7 kWatts Power Rating, 11.3 Amperes Continuous Output Current (0-peak), and 240 Volts (AC), 1 Phase, Input Voltage.

Repair Services for 2097-V32PR4-LM

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 2097-V32PR4-LM. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 2097-V32PR4-LM

Please refer to the manual for more information about the 2097-V32PR4-LM such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
2097-V32PR4-LM Ser A
2097-V32PR4-LM/A, Series A, Rev A Request Quote
Common misspellings:
  • 2o97-V32PR4-LM
  • 2097-V32PRA-LM
  • 2097-V32PR4-1M
  • 2097V32PR4LM

Reviews for 2097-V32PR4-LM

Product Review

"The 2097-V32PR4-LM is a single-axis, kinetix 350 servo drive. Unlike other Kinetix drives, the 2097-V32PR4-LM operates at a 1-phase, 240VAC input supply voltage. In addition, it comes with an integrated AC filter which eliminates the need of installing a separate AC line filter. This particular product number also comes with an integrated Safe-Torque Off (STO) functionality which enables it to be used in application with integrated safety requirement. " -DO Supply Tech
