Allen Bradley PowerFlex 4 22A-A4P5F104

Product image is representative; revision or series may vary. Contact us to request a specific version.

22A-A4P5F104

|
Need a Specific Revision?

The 22A-A4P5F104 drive is an AC-powered drive from the Allen-Bradley/Rockwell Automation PowerFlex 4 series. It can operate with a single-phase input voltage rating of 240 Volts AC and an input frequency rating of 50 to 60 Hertz. The 22A-A4P5F104 AC drive has no CE-compliant filter, but it is equipped with a brake and with a small control keypad. It can be flange-mounted inside an enclosure with an IP 20 environmental protection rating, or with a higher protection rating if required. The 22A-A4P5F104 AC drive operates with a maximum output current rating of 4.5 Amps.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 22A-A4P5F104

ManufacturerAllen Bradley
CategoryDrives
Product LinePowerFlex 4
Part Number22A-A4P5F104
Weight3.00 lbs (1.36 kg)
Amperage4.5
Enclosure TypeFlange-Mounted
FilterWithout CE Compliant Filter
Phase1 Phase
Wattage.75 Kilowatt
Input TypeKeypad
DisplayLight-Emitting Diode (LED)
Horsepower1 Horsepower
Input Power200-240 Volts AC
Brake DriveBrake Drive
View as PDF
Request a Repair

The Allen-Bradley 22A-A4P5F104 is a drive that belongs to the PowerFlex 4 series. It has a single-phase voltage input of 100 to 120 Volts AC whose output current and power are 4.5 Amps and 0.75 kW (1.0 Horsepower), respectively. It is also a flange mount-IP 20 (NEMA Type Open) drive. It can also serve as a three-phase drive with an AC voltage of 240 volts at 50 to 60 Hertz with 3% impedance with a 3.0mh inductance, 29W power loss, 8 Amps fundamental current, and 12 Amps continuous current. In addition, its dynamic brake resistance is a minimum of 48kVA.

The 22A-A4P5F104 is an HMI with a fixed keypad, a standard IGBT brake**,** and an RS-485 communication port, but no emissions filter. The height and width of the drive are 8.27 inches and 6.89 inches, respectively and the weight is 5.5 pounds.

Revision Part #Also known as
22A-A4P5F104 Ser A22A-A4P5F104/A, Series A, Rev A
Don't see your particular revision? Contact us now.
