Allen Bradley PowerFlex 4 22A-B017F104

Product image is representative; revision or series may vary. Contact us to request a specific version.

22A-B017F104

|
Need a Specific Revision?

The Allen-Bradley 22A-B017F104 drive is an AC-powered adjustable frequency drive. It is a member of the PowerFlex 4 drive series. The 22A-B017F104 adjustable frequency drive uses its adjustable frequency to adjust the speed and torque of a compatible variable speed motor. The 3-phase input voltage rating of this drive is 240 Volts AC at 50 to 60 Hertz. The 22A-B017F104 adjustable frequency drive has a Size B frame and an output current rating of 17.5 Amps.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 22A-B017F104

ManufacturerAllen Bradley
CategoryDrives
Product LinePowerFlex 4
Part Number22A-B017F104
Weight10.00 lbs (4.54 kg)
Amperage17
Enclosure TypeFlange-Mounted
FilterWithout CE Compliant Filter
Phase3 Phase
Wattage3.7 Kilowatt
Input TypeKeypad
DisplayLight-Emitting Diode (LED)
Horsepower5 Horsepower
Input Power200-240 Volts AC
Brake DriveBrake Drive
UPC820919217630
View as PDF
Request a Repair

The Allen-Bradley 22A-B017F104 brake drive is a PowerFlex 4 three-phase AC drive with a 4-digit LED display and LED status indicator lights. It has an IP20 enclosure rating and it is flange-mounted, but it does not have a filter that is CE-compliant. The input used on this brake drive is a fixed digital keypad and it also comes with an RS-485 communication port. Note that this drive has a B frame size. The 22A-B017F104 drive also has protective features, namely motor protection, over voltage protection, under voltage protection, over current protection, a control ride through feature, and a faultless ride through feature. It has an operating vibration of 1 g peak at 5-2000 Hz and an operating shock of 15 g peak for 11 ms (+/- 1 ms). This drive also comes with a 3.7 kW, 5 Hp, and 17.5 A output current. The 22A-B017F104’s input power is 200-240V AC and it has an input rating of 240V AC. Its operating temperature is -10-50 oC, its storage temperature is -40-85 oC, and its non-condensing storage and operating humidity is 0-95%.

Revision Part #Also known as
22A-B017F104 Ser A22A-B017F104/A, Series A, Rev A
Don't see your particular revision? Contact us now.
