22A-B4P5F104

The 22A-B4P5F104 PowerFlex4 Drive controls a machine’s speed and provides an interface through its fixed keypad and LED. PCs and other devices can connect through an RS-485 communication port. The drive has a unique output power rating of 0.75 kW (1 Horsepower) with an output current of 4.5 Amps. It has an input rating and voltage between 200 and 240 Volts AC, a current of 5.2 Amps, and an apparent power of 2.25 KVA. The 22A-B4P5F104 has a 140M-C2E-C10 motor protector and a 100-C09 contactor with 10 UL Class J (type) fuses**.** It also has a unique digital control which can be set to either source or sink mode via a DIP switch. Its programmable C relay control output with 0.5 Amps at 125 to 240 Volts AC inductive rating has an overall drive efficiency of 97.5%. It has an overvoltage protection and an overcurrent protection for hardware and circuitry at 200% limit and 300% instantaneous limit for 3s. It also has a motor overload protection at 150% overload for 60 seconds and a 200% overload for 3 seconds.

The 22A-B4P5F104 has a carrier frequency from 2 to 16 kHz, modulated with an accuracy of ±0.05% set within the digital control and 0.5% set with the analog control. It is fitted with multi-programmable stop modes and two independently programmable acceleration and deceleration modes programmed from 0 to 600 seconds for every increment of 0.1 seconds. The 22A-B4P5F104 has a dimension of 210 by 175 by 92.8 millimeters and a shipping weight of 2.49 kilograms
