22A-D6P0F104

The Allen-Bradley 22A-D6P0F104 is a PowerFlex 4 3-phase drive that has a flange-mounted IP20 enclosure and it has a frame size of Size B, but it does not come with a CE-compliant filter. However, it does come with an input power of 380-480V AC and a voltage rating of 480V AC. This AC brake drive also has a 6 A output current, and 3 Hp and 2.2 kW of output power. This drive is also equipped with a 4-digit LED display and status indicators that are also LEDs. The input used on the 22A-D6P0F104 drive is a keypad input, specifically a fixed digital keypad, and it comes with an RS-485 communication port. Its operating temperature ranges from 14-122 oF, its non-operating temperature is from -40-185 oF, and its non-condensing ambient relative humidity for operation and storage is from 0-95%. This AC drive also has an operating vibration of 1 g peak at 5-2000 Hz, as well as an operating shock of 15 g peak for 11 ms (+/- 1 ms). The 22A-D6P0F104 also comes with protective features, particularly protection against over current, over voltage, under voltage, motor protection, faultless power ride through, and control ride through. It is one of the safest and most efficient PowerFlex drives that Allen-Bradley manufactures.
