Powerflex 40P, 240 (208)VAC, 3PH, 2.3 Amps, 0.5 HP,Frame Size B, Panel Mount IP20 (NEMA Type Open), Display w/ Reset Only, Without CE compliant filter, AC Drive
Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 22D-B2P3N104.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

phone

International
919-205-4392
Rated 4.5 with 13 reviews
top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

22D-B2P3N104

Revisions: Ser A
Description: Powerflex 40P, 240 (208)VAC, 3PH, 2.3 Amps, 0.5 HP,Frame Size B, Panel Mount IP20 (NEMA Type Open), Display w/ Reset Only, Without CE compliant filter, AC Drive
Available Now
Request a quote for 22D-B2P3N104


top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 22D-B2P3N104.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.5 with 13 reviews

    Technical Specifications for 22D-B2P3N104

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.22D-B2P3N104
Product LinePowerflex 40P
Amperage2.3 A
PhaseThree-Phase
EnclosureOpen NEMA Type -Panel Mount (IP20)
Input Power240 Volts AC
Horsepower0.5 Horsepower
FilterNo CE Compliant Filter
TypeStandard
Frame SizeB
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.22D-B2P3N104
Product LinePowerflex 40P
Amperage2.3 A
PhaseThree-Phase
EnclosureOpen NEMA Type -Panel Mount (IP20)
Input Power240 Volts AC
Horsepower0.5 Horsepower
FilterNo CE Compliant Filter
TypeStandard
Frame SizeB

About 22D-B2P3N104

The Allen-Bradley 22D-B2P3N104 is a B Frame-sized adjustable frequency drive part of the PowerFlex 40P series featuring a reset button, a 4-digit display, a display/fault reset only type human interface module (HIM), a keypad input, and LED status indicators, but it does come with an EMC filter. This three-phase drive has a voltage rating of 240V AC, as well as 0.4 kW, 0.5 HP, and 2.3 A output current ratings at an input of 200 to 240V AC. For protection, this drive will undergo trips automatically upon reaching specific conditions. The bus overvoltage trip of the 22D-B2P3N104 drive is at 405V DC bus or 290V AC incoming line, while its bus undervoltage is at 210V DC bus or 150V AC incoming line voltage. The total Watts loss of this drive is 40W, made up of 22 external Watts and 18 internal Watts.



Two motor control options are available for this drive and these are the volts per Hertz control and the sensorless motor control. This panel-mounted drive comes with a NEMA Type open, IP20 enclosure rating and it must operate at an altitude of not more than 1000 m and with temperatures ranging from 14 to 122 °F or -10 to 50 °C and should be stored at -40 to 185 °F or -40 to 85 °C temperatures. Also found on the 22D-B2P3N104 drive are various inputs and outputs and these are 5 fully programmable digital inputs, 2 semi-programmable digital inputs, 1 form C relay output that is fully programmable, 2 opto outputs, 1 DIP switch selectable analog input, and 1 DIP switch selectable analog output.

Repair Services for 22D-B2P3N104

Type Lead Time Price Action
Repair Service 2-4 weeks $468.68cartAdd to Cart

Our highly skilled technicians can repair your 22D-B2P3N104. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 22D-B2P3N104

Please refer to the manual for more information about the 22D-B2P3N104 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
22D-B2P3N104 Ser A
22D-B2P3N104/A, Series A, Rev A Request Quote
