150-F108NZD

Revisions: Ser A
Description: Solid State Controller with open enclosure, 108 A, 75 Hp @ 460V AC Controller Rating, and 230-690V AC, 3-phase, 50 and 60 Hz Input Line
Call
Request a quote for 150-F108NZD

Description: Solid State Controller with open enclosure, 108 A, 75 Hp @ 460V AC Controller Rating, and 230-690V AC, 3-phase, 50 and 60 Hz Input Line

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Allen Bradley.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 150-F108NZD.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4 with 9 reviews

    Technical Specifications for 150-F108NZD

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.150-F108NZD
Product LineSMC-Flex
Bulletin NumberSolid State Controller
Enclosure Typeopen
Controller Rating108 A, 75 Hp @ 460V AC
Input Line Voltage230-690V AC, 3-phase, 50 and 60 Hz
Control Voltage100-240V AC (5-480 A units)
Rated Voltage690/Y§V AC
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.150-F108NZD
Product LineSMC-Flex
Bulletin NumberSolid State Controller
Enclosure Typeopen
Controller Rating108 A, 75 Hp @ 460V AC
Input Line Voltage230-690V AC, 3-phase, 50 and 60 Hz
Control Voltage100-240V AC (5-480 A units)
Rated Voltage690/Y§V AC
s

About 150-F108NZD

The 150-F108NZD is an Allen-Bradley solid-state controller which belongs to the SMC – Flex series. It features a controller rating of 108 Amps, 75 Horsepower at 460 Volts AC. It also has a rated voltage of 690 Volts AC. The controller’s input voltage is 230 to 690 Volts AC. It also has three-phase cage induction features. Moreover, it has three-phase, 50 and 60 Hertz frequency. The control voltage that is exhibited by this drive is 100 to 240 Volts AC which is also equivalent to 5 to 480 Amps. This device is made to drive squirrel cage induction and wye-delta motors. It is part of a product line of soft starters that includes non-combination models and combination models. It has seven embedded standard start modes. This device is also made to aid operators in controlling loads which are resistive.





The electronic motors overload protection in the 150-F108NZD helps to give it protection against excessive currents. The SCR bypass also offers additional protection. The enclosure that this device has serves to give it physical protection against damage. It also has an optional function which the user may use to support motor braking or an accu stop. Using this device aids operators in reducing energy costs while enhancing scalability. Moreover, it also has three standard operating modes which are the full voltage start, the soft start, and the current limit start. The 150-F108NZD can be controlled easily while starting, stopping and adjusting the module and its settings. The 150-F108NZD is designed to operate with an electromechanical motor starter. This starter aids this device especially when it needs to eliminate additional control wiring. This simplifies the process of installing this device. The electromechanical motor starter also helps the users to set up digital adjustments. If the operators feel that this device is not well protected, they can add another protective module to protect it further from damage.



Repair Services for 150-F108NZD

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 150-F108NZD. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 150-F108NZD

Please refer to the manual for more information about the 150-F108NZD such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
150-F108NZD Ser A
150-F108NZD/A, Series A, Rev A Request Quote
Common misspellings:
  • l50-F108NZD
  • 15o-F108NZD
  • 150-Fl08NZD
  • 150-F1o8NZD
  • 150-F10bNZD
  • 150F108NZD

Dimensions For 150-F108NZD

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 150-F108NZD

Width 7.74 in. (196.4 mm)
Height 17.47 in. (443.7 mm)
Depth 8.35 in. (212.2 mm)
Approx Ship. Wt. 33 lb (15 kg)
