Allen Bradley 500 Contactors 500-GOB930

Product image is representative; revision or series may vary. Contact us to request a specific version.

500-GOB930

|
Need a Specific Revision?

The Allen-Bradley 500-GOB930 contactor is a series 500 AC contactor. The continuous current rating of the 500-GOB930 contactor is 540 Amps.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 500-GOB930

ManufacturerAllen Bradley
Product TypeContactor
Product Line500 Contactors
Part Number500-GOB930
UPC662072470107
Weight52.00 lbs (23.59 kg)
Current Rating540 Amps
NEMA Size6
EnclosureOpen
Coil Voltage440/480 Volts AC
Number of Poles3
Auxiliary ContactYes
WiringFeedthrough
Mechanical Life5 million operations
Peak Inrush Current6326 Amps
Request a Repair

The 500-GOB930 contactor is an Allen-Bradley Bulletin 500 contactor. It is available as a NEMA size 6 device which has continuous current rating of 540 Amps. The enclosure of the contactor is open. The nominal coil voltage rating is 440 Volts AC at 50 Hertz and 480 Volts AC at 60 Hertz. The 500-GOB930 contactor comes with 3 power poles and one auxiliary contact. The maximum motor horsepower rating is 150 Horsepower at 200 Volts AC, 200 Horsepower at 230 Volts AC, 300 Horsepower at 380 to 415 Volts AC, and 400 Horsepower at 460 to 575 Volts AC. The size 6 500-GOB930 contactor has feedthrough wiring and it is available as a complete factory assembled unit. The peak circuit closing inrush current rating for the contactor is 6326 Amps.

The service limit current rating for the 500-GOB930 contactor is 621 Amps. The 3-phase peak horsepower rating for non-plugging and non-jogging duty at 200 Volts AC voltage is 75 Horsepower. The 3-phase peak horsepower rating for the plugging and jogging duty at 200 Volts AC voltage is 60 Horsepower. The 3-phase peak horsepower rating for the non-plugging and non-jogging duty at 575 Volts AC voltage is 200 Horsepower. The 3-phase peak horsepower rating for the plugging and jogging duty at 575 Volts AC voltage is 150 Horsepower. The rated mechanical life of the contactor is about 5 million operations. A NEMA size 6 contactor can have a maximum of 4 auxiliary contacts. The average pick-up time and drop-out time for the contactor are 25 to 79 milliseconds and 10 to 22 milliseconds, respectively.
