Allen Bradley 889 Cordsets and Patchcords 889D-F4AC-10

Product image is representative; revision or series may vary. Contact us to request a specific version.

889D-F4AC-10

|
Need a Specific Revision?

The 889D-F4AC-10 quick-disconnect cordset from Allen Bradley is engineered for DC micro applications, featuring a sturdy construction for reliable use. With a length of 10 meters and a cable jacket made from yellow PVC, this cordset offers both visibility and durability.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 889D-F4AC-10

ManufacturerAllen Bradley
Product TypeQuick-Disconnect Cordset (DC Micro Set)
Product Line889 Cordsets and Patchcords
Part Number889D-F4AC-10
Weight1.00 lbs (0.45 kg)
UPC662072825426
Cable Length10 m
Cable Jacket MaterialYellow PVC
Wire Rating22 AWG
Connector StyleStraight Connector
Coupling NutEpoxy-coated zinc
Contact MaterialGold over nickel-plated brass
Enclosure RatingIP67, NEMA 6P
Minimum Operating Temperature-20°C
Maximum Operating Temperature105°C
Relative Humidity5 to 95% (non-condensing)
Request a Repair

Designed for versatility, the 889D-F4AC-10 from Allen Bradley is a quick-disconnect cordset suited for DC micro applications. It includes a 10-meter cable length, covered with a yellow PVC jacket for enhanced identification and protection against wear. The wire rating is at 22 AWG, serving standard applications effectively. This cordset incorporates a straight connector style that helps facilitate easy connections without complications.

The coupling nut is composed of epoxy-coated zinc, which contributes to the overall durability of the assembly. For the contacts, the material used is gold over nickel-plated brass, ensuring good conductivity and resistance to corrosion over time. The device holds an IP67 rating, as well as adhering to NEMA 6P standards, which confirms its capability to withstand both dust and moisture.

Operating temperature ranges from -20 degrees Celsius to a maximum of 105 degrees Celsius. Additionally, it maintains functionality in relative humidity environments ranging from 5 to 95 percent without condensation, making it suitable for a variety of industrial environments. The combination of these features ensures that the 889D-F4AC-10 cordset provides reliable performance in demanding conditions.
