Product image is representative; revision or series may vary. Contact us to request a specific version.
VPL-B0753E-PJ14AA
The VPL-B0753E-PJ14AA brushless servo motor is a low-inertia permanent magnet servo motor that has been designed and manufactured by Allen-Bradley/Rockwell Automation. It is a member of the Allen-Bradley VPL series of brushless servo motors. The VPL-B0753E-PJ14AA brushless servo motor’s shaft supports a maximum rotation speed of 3500 RPM and it can be held at 0 RPM by the motor’s 24 Volts DC holding brake until the required torque rating is achieved. This servo motor also supports a voltage rating of 400 Volts. The VPL-B0753E-PJ14AA brushless servo motor comes with a digital feedback encoder which is an absolute multi-turn type of digital feedback encoder.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for VPL-B0753E-PJ14AA
| Manufacturer | Allen Bradley |
|---|---|
| Product Type | Low-Inertia Servo Motor |
| Product Line | VPL Servo Motors |
| Part Number | VPL-B0753E-PJ14AA |
| UPC | 885630980072 |
| Weight | 10.06 lbs (4.56 kg) |
| Voltage | 400 Volts AC |
| Frame Size | 75 millimeters |
| Rated Speed | 3500 RPM |
| Magnet Stacks | 3 |
| Feedback | 18-bit absolute multi-turn digital encoder (Hiperface DSL protocol) |
| Shaft | Shaft Key |
| Connector | Single SpeedTec DIN connector, right angle, 325° rotatable |
| Mounting Flange | IEC metric, free mounting holes (type FF) |
| Factory Options | Standard |
| Brake | 24 Volts DC |
The VPL-B0753E-PJ14AA is a low-inertia servo motor from Allen-Bradley. The motor has 3 magnetic stacks and an operating voltage of 480 Volts AC. The VPL-B0753E-PJ14AA belongs to the Kinetix VP series. Motors in this series are brushless and they are designed to meet the strict requirements of the motion system. The VPL-B0753E-PJ14AA, as with other bulletin VPL Kinetix low-inertia motors, is optimized to provide a low-cost option that is energy efficient. Also, motors in this bulletin are manufactured from a mirror of the reliable technology used to manufacture the MP-series motors. The VPL-B0753E-PJ14AA has a speed rating of 3500 revolutions per minute and an 18-bit absolute multi-turn feedback encoder. The encoder accommodates 4096 revolutions and a Hiperface DSL protocol.
The VPL-B0753E-PJ14AA contains a 24 Volts DC brake. To interface the motor with other devices, a 325 degrees rotatable, right-angled, SpeedTec DIN connector is available. As with other Kinetix VP low-inertia motors, the VPL-B0753E-PJ14AA has a high torque to size ratio, and it is CE marked and UL listed. This group of motors is also designed to be compatible with the ratings of Kinetix 5700 and Kinetix 5500 drives. The VPL-B0753E-PJ14AA has a 75 millimeters bolt circle frame size and it is mounted on an IEC metric mounting flange. To avoid communication and performance interference, the cables used to set up the system should be routed on different paths. This, in turn, helps to prevent ElectroMagnetic Interference (EMI). Apart from routing, using shielded cables and observing grounding rules will help generate the same effect.
| Revision Part # | Also known as | |
|---|---|---|
| VPL-B0753E-PJ14AA Ser A | VPL-B0753E-PJ14AA/A, Series A, Rev A | |
| Don't see your particular revision? Contact us now. | ||
- VPL-80753E-PJ14AA
- VPL-8O753E-PJIAAA
- VPL-B0753E-PJ1AAA
- VPL-B0753E-PJI4AA
- VPL-BO753E-PJ14AA
- VPL80753EPJ14AA
- VPL8O753EPJIAAA
- VPLB0753EPJ14AA
- VPLB0753EPJ1AAA
- VPLB0753EPJI4AA
- VPLBO753EPJ14AA
The Allen-Bradley VPL-B0753E-PJ14AA Low-inertia Servo Motor has a 400V Voltage and a 3500 rpm Rated Speed. It also contains a 75 mm Frame Size and an IEC metric, free mounting holes (type FF) Mounting Flange.
