Allen Bradley ArmorPoint Modules 1738-IB8M12

1738-IB8M12

|
Need a Specific Revision?

The Allen-Bradley/Rockwell Automation DC input module with the product code 1738-IB8M12 is part of the ArmorPoint I/O product series. The 1738-IB8M12 module comes with a mounting base and M12-style micro connectors. The module has an IP 67-rated housing and small dimensions. The 1738-IB8M12 module comes with a single group of 8 non-isolated and sinking inputs.

$231
Ships Mon, Jul 14
64 in stock
$188
Ships Mon, Jul 14
2 in stock
$154
Ships Mon, Jul 14
17 in stock
Ships Mon, Jul 14.
In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.
Learn more
  • Warranty

    We sell industrial automation parts backed by our 2-year DO Supply Warranty.

  • Shipping

    Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.

  • Payment Methods

    AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.

  • Repairs & Exchanges

    Repairs and exchanges are available for all automation products.

  • Reseller Options

    Drop shipping, blind shipping, and account shipping with no extra fees.

Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for 1738-IB8M12

BrandAllen-Bradley / Rockwell Automation
SeriesArmorPoint Modules
Part Number1738-IB8M12
Type of ComponentDC Input Module
Connector TypeM12 (Micro)
Inputs per Module8 (1 Group of 8) Non-Isolated Sinking Inputs
Input Voltage (Nominal), On-State24 Volts DC
Input Voltage (Maximum), Off-State5 Volts DC
Input Current (Nominal), On-State4 milliamps at 24 Volts DC
Input Current (Maximum), Off-State1.5 milliamps
HousingIP 67, Sealed
Operating Temperature-20 to 60 degrees Celsius (-4 to 140 degrees Fahrenheit)
Storage Temperature-40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Certificationsc-UL-us, CE, C-Tick
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
Request a Repair

The catalog number 1738-IB8M12 is used for an Allen-Bradley/Rockwell Automation ArmorPoint I/O series input module that operates at 24 Volts DC. The module is equipped with 8 inputs with M12 micro connectors. The available inputs are all grouped together in 1 group of 8 and these inputs are all non-isolating and sinking types of inputs. The 1738-IB8M12 module has an IP 67 protection rating for its enclosure. This enclosure can protect the module from most environmental hazards such as dust, water, other liquids, and chemicals. The 1738-IB8M12 module is built for use in environments where Overvoltage Category II applications are carried out. The device can be installed at altitudes up to 2000 meters above sea level without derating and stored in places where the temperature is between -40 and 85 degrees Celsius (-40 and 185 degrees Fahrenheit).

The 1738-IB8M12 ArmorPoint input module includes indicators for module status updates and network status updates. Additionally, the 1738-IB8M12 input module has 8 I/O status indicators, 1 for each input. The indicators on the module show the users when the device is turned off and when it is operating normally. The indicators will also show the users when the module needs to be configured or reconfigured for any reason or when it is experiencing an active fault. The network status indicators will show the users whether the module is connected to a network or not. When an indicator is flashing red, this indicates a system error such as a critical link failure. The 1738-IB8M12 module meets various standards for shock immunity, vibration immunity, EFT/B immunity, surge transient immunity, and emissions. The module is manufactured in accordance with all the required industrial standards and it includes CE and C-Tick certifications.
