1771-OJ - In Stock | Allen Bradley PLC PLC 5

×

1771-OJ

Rated 4.9 with 3 reviews
About | Product Specifications

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.


credit cards accepted
better business bureau

1771-OJ

Revisions: Ser A
Description: The Allen-Bradley 1771-OJ output module is a pulse output expander module from the Allen-Bradley/Rockwell Automation PLC 5 series. It comes with a field wiring arm known as the Allen-Bradley 1771-WB field wiring arm. The 1771-OJ pulse output expander module can be used along with a stepper controller module and a field wiring arm to create a complete stepper motor positioning assembly. Up to 3 pulse output expander modules like the 1771-OJ module can be controlled by the same stepper controller module. The 1771-OJ pulse output expander module is designed to be used in 1-axis machine applications.
In Stock Ships Today
Request a quote for 1771-OJ

Description: The Allen-Bradley 1771-OJ output module is a pulse output expander module from the Allen-Bradley/Rockwell Automation PLC 5 series. It comes with a field wiring arm known as the Allen-Bradley 1771-WB field wiring arm. The 1771-OJ pulse output expander module can be used along with a stepper controller module and a field wiring arm to create a complete stepper motor positioning assembly. Up to 3 pulse output expander modules like the 1771-OJ module can be controlled by the same stepper controller module. The 1771-OJ pulse output expander module is designed to be used in 1-axis machine applications.
About | Products Specs

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1771-OJ.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.9 with 3 reviews

    Technical Specifications for 1771-OJ

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OJ
Module TypePulse Output Expander Module
Inputs5-30 Volt DC Digital Inputs for Jogging and E-Stop
Max Input FrequencyN/A
Outputs20 Kilohertz Output to Translator Source/Sink Push-Pull
Slots1 Per OJ
Module Update Period2.4-3.1 ms
Backplane Current0.80 Amperes
Wiring Arm1771-WB
Model StatusEarlier Model
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
UPC10612598003195
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OJ
Module TypePulse Output Expander Module
Inputs5-30 Volt DC Digital Inputs for Jogging and E-Stop
Max Input FrequencyN/A
Outputs20 Kilohertz Output to Translator Source/Sink Push-Pull
Slots1 Per OJ
Module Update Period2.4-3.1 ms
Backplane Current0.80 Amperes
Wiring Arm1771-WB
Model StatusEarlier Model
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
UPC10612598003195
s

About 1771-OJ

The 1771-OJ PLC 5 Pulse Output Expander Module by Allen-Bradley is a component of the Stepper Motor Positioning Assembly which provides programmable control of the stepper motor of the programmable controller and provides modular expansion of axes from 1 to 3 axis per I/O chassis. The expander module draws 800mA at 5V DC backplane current and it uses an auxiliary power supply with a power rating of +5-30V DC at 340mA (max) with a peak-to-peak ripple less than the specified value for the stepper translator. The 1771-OJ supports 2 input modes (JUG and STOP) with an input signal delay time of 35-120ms from 1 axis through 3 axes in the JUG mode and the signal is a delay for 250ms in the STOP mode.

The 1771-OJ has a voltage range of 1.0V (High) and 0.8V DC (Low state) and with an internal 1.6 Kilo Ohms pull-resistor, the module is compatible with Open Collector Logic Devices. It has a maximum ON-state current of 2.3mA per input at 5V DC and 18.6mA at 30V DC and an output voltage range of -2.6V DC (High), and +0.7V DC (low) at 100mA output current, and the maximum output current of the module is 100mA. The 1771-OJ has 0.6ms worst case rise/fall time at 100mA maximum current and it has a 50% pulse duty cycle. The module uses a 40ft Belden 8771 stranded copper wire with a single wire per terminal and it is keyed to the I/O backplane by inserting connector bands between pins 8 and 10 and pins 22 and 24. The 1771-OJ’s operating temperature range is 0-60 0C at 5-95% non-condensing humidity and the module is CE, CSA, UL, and C-TICK certified.



Technical Description of 1771-OJ

Allen Bradley PLC 5 Pulse Output Expander Module, 5-30 Volt DC Digital Inputs for Jogging and E-Stop, 20 Kilohertz Output to Translator Source/Sink Push-Pull, 0.80 Amperes Backplane Current

Repair Services for 1771-OJ

Type Lead Time Price Action
Repair Service 2-4 weeks $1357cartAdd to Cart

Our highly skilled technicians can repair your 1771-OJ. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1771-OJ

Please refer to the manual for more information about the 1771-OJ such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1771-OJ Ser A
1771-OJ/A, Series A, Rev A Request Quote
Common misspellings:
  • l771-OJ
  • 177l-OJ
  • 1771-0J
  • 1771OJ

Dimensions For 1771-OJ

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 1771-OJ

Resolutions For 1771-OJ

About

Technical Specifications for 1771-OJ

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OJ
Module TypePulse Output Expander Module
Inputs5-30 Volt DC Digital Inputs for Jogging and E-Stop
Max Input FrequencyN/A
Outputs20 Kilohertz Output to Translator Source/Sink Push-Pull
Slots1 Per OJ
Module Update Period2.4-3.1 ms
Backplane Current0.80 Amperes
Wiring Arm1771-WB
Model StatusEarlier Model
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
UPC10612598003195
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OJ
Module TypePulse Output Expander Module
Inputs5-30 Volt DC Digital Inputs for Jogging and E-Stop
Max Input FrequencyN/A
Outputs20 Kilohertz Output to Translator Source/Sink Push-Pull
Slots1 Per OJ
Module Update Period2.4-3.1 ms
Backplane Current0.80 Amperes
Wiring Arm1771-WB
Model StatusEarlier Model
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
UPC10612598003195

About 1771-OJ

The 1771-OJ PLC 5 Pulse Output Expander Module by Allen-Bradley is a component of the Stepper Motor Positioning Assembly which provides programmable control of the stepper motor of the programmable controller and provides modular expansion of axes from 1 to 3 axis per I/O chassis. The expander module draws 800mA at 5V DC backplane current and it uses an auxiliary power supply with a power rating of +5-30V DC at 340mA (max) with a peak-to-peak ripple less than the specified value for the stepper translator. The 1771-OJ supports 2 input modes (JUG and STOP) with an input signal delay time of 35-120ms from 1 axis through 3 axes in the JUG mode and the signal is a delay for 250ms in the STOP mode.

The 1771-OJ has a voltage range of 1.0V (High) and 0.8V DC (Low state) and with an internal 1.6 Kilo Ohms pull-resistor, the module is compatible with Open Collector Logic Devices. It has a maximum ON-state current of 2.3mA per input at 5V DC and 18.6mA at 30V DC and an output voltage range of -2.6V DC (High), and +0.7V DC (low) at 100mA output current, and the maximum output current of the module is 100mA. The 1771-OJ has 0.6ms worst case rise/fall time at 100mA maximum current and it has a 50% pulse duty cycle. The module uses a 40ft Belden 8771 stranded copper wire with a single wire per terminal and it is keyed to the I/O backplane by inserting connector bands between pins 8 and 10 and pins 22 and 24. The 1771-OJ’s operating temperature range is 0-60 0C at 5-95% non-condensing humidity and the module is CE, CSA, UL, and C-TICK certified.



Technical Description of 1771-OJ

Allen Bradley PLC 5 Pulse Output Expander Module, 5-30 Volt DC Digital Inputs for Jogging and E-Stop, 20 Kilohertz Output to Translator Source/Sink Push-Pull, 0.80 Amperes Backplane Current
Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks $1357cartAdd to Cart

Our highly skilled technicians can repair your 1771-OJ. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks $1357cartAdd to Cart

Our highly skilled technicians can repair your 1771-OJ. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions

Please refer to the manual for more information about the 1771-OJ such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1771-OJ Ser A
1771-OJ/A, Series A, Rev A Request Quote

Common misspellings:
  • l771-OJ
  • 177l-OJ
  • 1771-0J
  • 1771OJ
PDF
1771-OJ PDF
