1771-OR

Revisions: Ser A Ser B
Description: The 1771-OR digital output module is a PLC 5 series digital AC-powered output module that has been designed and manufactured by Allen-Bradley/Rockwell Automation. It comes with 6 output channels and it can support up to 2 Amps of current per output channel. The 1771-OR digital AC output module is manufactured in the 220 Volts AC voltage category in the PLC 5 product line, and it operates at 184 to 276 Volts AC voltage and at 47 to 63 Hertz of frequency. The 1771-OR digital AC output module is powered through the chassis backplane and it uses 255 milliamps of backplane current at 5 Volts DC.
Available Now
Request a quote for 1771-OR

Description: The 1771-OR digital output module is a PLC 5 series digital AC-powered output module that has been designed and manufactured by Allen-Bradley/Rockwell Automation. It comes with 6 output channels and it can support up to 2 Amps of current per output channel. The 1771-OR digital AC output module is manufactured in the 220 Volts AC voltage category in the PLC 5 product line, and it operates at 184 to 276 Volts AC voltage and at 47 to 63 Hertz of frequency. The 1771-OR digital AC output module is powered through the chassis backplane and it uses 255 milliamps of backplane current at 5 Volts DC.

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1771-OR.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.7 with 14 reviews

    Technical Specifications for 1771-OR

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OR
Module TypeDigital AC Output Module
Number of Outputs6 Outputs
Voltage Category220 Volts AC
AC Operating Voltage184-276 Volts
Backplane Current255 Miliamperes
Max Continuous Current Per Output2 Amperes
ListingThis specification list has been compiled by DO Supply.
Max Current Per Module6 Amperes
Wiring Arm1771-WD
CoatingConformal Coat
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-OR
Module TypeDigital AC Output Module
Number of Outputs6 Outputs
Voltage Category220 Volts AC
AC Operating Voltage184-276 Volts
Backplane Current255 Miliamperes
Max Continuous Current Per Output2 Amperes
Max Current Per Module6 Amperes
Wiring Arm1771-WD
CoatingConformal Coat
CoatingConformal Coat
Typical AC Signal Delay (Off)45 (+/- 15) ms
Typical DC Signal Delay (Off)50 ms
Wiring Arm1771-WH
MountingRack Mountable
s

About 1771-OR

The Allen-Bradley 1771-OR is part of the 1771 Digital AC Output Modules that may be used with either of the 1771 Series A or B I/O chassis. This module’s output of the tricacs comes with surge suppression. Between each terminal set is an MOV or metal oxide varistor that suppresses spikes or high voltage transients from the AC line. RC networks limit the effect of voltage transients from devices with inductive loads or hard contacts. This cost-efficient feature enhances power quality, optimizes product life, and prevents downtime.

The 1771-OR AC Isolated Output Module is composed of 6 outputs and comes with a nominal output voltage of 220V AC, 50-60Hz. It has an output voltage range of 184-276V AC at 47 - 63Hz, with a current rating of 2A per output (it should not exceed 6A per module). Its maximum surge current is rated at 15A per output for 100ms and it is repeatable every 2 seconds. The 1771-OR requires 255mA at 5V DC ±5% 1771 I/O chassis backplane current through the chassis power supply.

The front panel of the 1771-OR AC features 12 indicators. The first six indicators at the top show each of the output’s energy state –driven by the logic circuitry on the controller side. The bottom six signals a blown fuse, corresponding each of the output.



Technical Description of 1771-OR

Allen Bradley PLC 5 Digital AC Output Module, 6 Outputs, 184-276 Volts AC Operating Voltage, 255 Miliamperes Backplane Current
