1771-P5E

Revisions: Ser A Ser B
Description: Allen Bradley PLC 5 Power Supply, 24 Volts DC (Selectable Power-Loss Time Delay) Nom Input Voltage, 20.5-30 Volts DC Input Voltage Range, 8 Amperes (at 5 Volts DC) Backplane Output Current
In Stock Ships Today
Request a quote for 1771-P5E

Description:

Allen Bradley PLC 5 Power Supply, 24 Volts DC (Selectable Power-Loss Time Delay) Nom Input Voltage, 20.5-30 Volts DC Input Voltage Range, 8 Amperes (at 5 Volts DC) Backplane Output Current



no auth
no auth mobile
disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1771-P5E.
Exchange: Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.2 with 13 reviews

    Technical Specifications for 1771-P5E

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-P5E
Module TypePower Supply
Nom Input Voltage24 Volts DC (Selectable Power-Loss Time Delay)
Input Voltage Range20.5-30 Volts DC
Max Real Input Power57 Watts
Max Apparent Input PowerN/A
Max Xformer LoadN/A
User Output CurrentN/A
Backplane Output Current8 Amperes (at 5 Volts DC)
FrequencyDC/Rect Sine
Fuse5 Amperes, 32 Volts, Normal-Blow
Cabling1771-CT
Paralleled-P10, -P5
Dimensions2 Chassis Slot
Weight2.3 lbs (1 kg)
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1771-P5E
Module TypePower Supply
Nom Input Voltage24 Volts DC (Selectable Power-Loss Time Delay)
Input Voltage Range20.5-30 Volts DC
Max Real Input Power57 Watts
Max Apparent Input PowerN/A
Max Xformer LoadN/A
User Output CurrentN/A
Backplane Output Current8 Amperes (at 5 Volts DC)
FrequencyDC/Rect Sine
Fuse5 Amperes, 32 Volts, Normal-Blow
Cabling1771-CT
Paralleled-P10, -P5
Dimensions2 Chassis Slot
Weight2.3 lbs (1 kg)

About 1771-P5E

The 1771-P5E Power Supply Module by Allen-Bradley is a double slot, chassis-based power supply module with 20.5-30V DC input voltage and a selectable power loss delay feature and it provides the 1771 Chassis with 5V DC power. The module has 24V DC nominal input voltage and supplies an output voltage of 5.06V DC with an output current of 8A (max). It has an input power of 57W and dissipates 4W at 2A, 7W at 4A, 12W at 6A, and 17W at 7A. The 1771-P5E is uniquely designed to connect with another in parallel for a greater chassis current and must not be connected in parallel with any other power supply module. It provides circuit protection via the 5A, 32V DC Normal Bow fuse, and can also provide branch circuit protection at 15A maximum.
It has a Green indicator light which shows the status of the module while operational and the module performs self-diagnostic and in the case of over voltage, under voltage, and overcurrent, the 1771-P5E will automatically shut down for about 45s before coming online again. It has a selectable power loss delay time of 13.6ms (+-3.6ms) or 60ms the module uses a 2.5mm2 copper wire with 1.2mm thick insulation as the circuit conductor. It is IEC-tested to function at 0-60 0C and 5-95% non-condensing relative humidity without de-rating and the module is designed with an open-style enclosure. The 1771-P5E is UL, CSA, CE, and C-TICK-certified and it weighs about 2.6 pounds.

Repair Services for 1771-P5E

Type Lead Time Price Action
Repair Service 2-4 weeks $483.52cartAdd to Cart

Our highly skilled technicians can repair your 1771-P5E. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1771-P5E

Please refer to the manual for more information about the 1771-P5E such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
