1771-TCMR

Revisions: Ser A
Description: Allen Bradley PLC 5 Process Control I/O Module, 1 Slot, Natural Binary 16-Bit Integer Data Format, 1.5 Amperes Backplane Current
Available Now
Request a quote for 1771-TCMR

Description:

Allen Bradley PLC 5 Process Control I/O Module, 1 Slot, Natural Binary 16-Bit Integer Data Format, 1.5 Amperes Backplane Current


DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1771-TCMR.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 7 reviews

    Technical Specifications for 1771-TCMR

Manufacturer
BrandAllen-Bradley
Part Number/Catalog No.1771-TCMR
Module TypeProcess Control I/O Module
Number of Inputs & Outputs8 Temperature Inputs (for 8 PID heat/cool loops)
Input/Output Resolution16-Bit Resolution or 15 Bits + Sign Bit
Analog InputsRTD
Analog OutputsN/A
Slots1 Slot
Data FormatNatural Binary 16-Bit Integer
Backplane Current1.5 Amperes
I/O Connection Hardware1771-RTP1
Required External PowerNone
Typical AC Signal Delay (Off)29 (+/- 8) ms
Typical DC Signal Delay (Off)30 (+/- 7) ms
Wiring Arm1771-WN
Dimensions4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm)
Manufacturer
BrandAllen-Bradley
Part Number/Catalog No.1771-TCMR
Module TypeProcess Control I/O Module
Number of Inputs & Outputs8 Temperature Inputs (for 8 PID heat/cool loops)
Input/Output Resolution16-Bit Resolution or 15 Bits + Sign Bit
Analog InputsRTD
Analog OutputsN/A
Slots1 Slot
Data FormatNatural Binary 16-Bit Integer
Backplane Current1.5 Amperes
I/O Connection Hardware1771-RTP1
Required External PowerNone
Typical AC Signal Delay (Off)29 (+/- 8) ms
Typical DC Signal Delay (Off)30 (+/- 7) ms
Wiring Arm1771-WN
Dimensions4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm)
s

About 1771-TCMR

The 1771-TCMR control module is a temperature control module for resistance sensors from Allen-Bradley. It can be used in an I/O chassis with the Allen-Bradley 1771-ASB adapter.  The 1771-TCMR control module can use multiple resistance sensors that include 100 Ohms platinum (USA), 100 Ohms platinum (European), 120 Ohms nickel, and 10 Ohms copper sensors. The input to the module comes through the Allen-Bradley 1771-RTP-4 remote termination panel. The features available on the 1771-TCMR control module include 8 separate heat/cool temperature control loops, a unique startup algorithm, auto-tuning of the PID loops, 16-bit analog to digital conversion, self-calibration, and input open-circuit detection. The module can be installed in any chassis slot. The first calibration of the module is recommended after 6 months. Subsequent calibrations can be performed once a year.



The 1771-TCMR control module is designed to withstand 1000 Volts DC continuous voltage between input channels and also between the input channels and the backplane connections. The steady-state current for series A 1771-TCMR control modules is 1.3 Amps. The current surge at power turn-on for series B 1771-TCMR control modules is 1.5 Amps. The operating range of temperature for the 1771-TCMR control module is 0 to 60 degrees Celsius. Changes in ambient temperature which are greater than 0.5 degrees Celsius per minute can lead to performance degradation. In storage, the ambient temperature around the module should be between –40 and 85 degrees Celsius. The 1771-TCMR control module weighs 1.8 pounds. The input impedance exceeds 10 megaohms. The time taken to detect open inputs is 5 seconds maximum. The input bandwidth is 9 Hertz. Update time for all 8 loops is 1 second.



Repair Services for 1771-TCMR

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1771-TCMR. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1771-TCMR

Please refer to the manual for more information about the 1771-TCMR such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1771-TCMR Ser A
1771-TCMR/A, Series A, Rev A Request Quote
