Allen Bradley RediPanel 2705-P11J1

Product image is representative; revision or series may vary. Contact us to request a specific version.

2705-P11J1

|
Need a Specific Revision?

The 2705-P11J1 RediPanel Pushbutton Unit is a pushbutton terminal with 32 illuminated pushbuttons. It has 120 to 240 Volts AC input voltage and 260 milliAmps current ratings.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 2705-P11J1

ManufacturerAllen Bradley
CategoryPLCs
Product LineRediPanel
Part Number2705-P11J1
Weight9.75 lbs (4.42 kg)
DescriptionRediPanel 800A Push-Button Unit
ConfigurationDIP Switches
CommunicationRemote I/O Data Link
Input Voltage120/240 Volt AC
Current Rating260 mill-Amps
Enclosure TypeNEMA 13 (IP65)
LEDYes
Push Buttons32
Request a Repair

The Allen-Bradley 2705-P11J1 RediPanel Standard Terminal is a pushbutton I/O unit that belongs to the Bulletin 800A RediPanel Operator Module product line and that is designed to communicate readily with the Allen-Bradley PLC Controllers over the Remote I/O network for the easy installation and configuration of push-buttons. The 2705-P11J1 Terminal is a standard 16-millimeter unit designed to operate in Class 1 Division 2, Groups A, B, C, and D hazardous locations (abnormal locations with flammable gasses, liquids, and vapors in them), and it comes with a NEMA Type 12/13 (IP 65) industrial enclosure. Similar to all RediPanel pushbutton modules, the 2705-P11J1 Terminal comes with built-in diagnostic features that allow for smooth operation and control.

The 2705-P11J1 Terminal has an integral AC power supply with an operating voltage range of 90 to 264 Volts AC (at 47 to 63 Hertz), and it has an input current rating of 260 milliamps at 120 Volts AC. The 2705-P11J1 Terminal comes with a standard pushbutton configuration with 32 momentary incandescent-lamp illuminated pushbuttons (8 green, 8 red, 8 amber, and 8 white). The 2705-P11J1 Terminal is supplied with a standard 3-prong female communication connector, and a user-supplied I/O connector cable (the 1770-CD or Belden 9463 cable) can be ordered separately for I/O connections. The 2705-P11J1 communicates directly with the Allen-Bradley Programmable Logic Controller family over the serial datalink by using the supported Allen-Bradley 1747, 1771, 1772, 1775, and 5250-RS scanner modules. It offers adjustable baud rates over a maximum I/O distance of 10,000 feet. The 2705-P11J1 Terminal has an operating temperature range of 0 to 60 degrees Celsius, and it can be used within a 5 to 95% non-condensing relative humidity range.
