1783-US4T1H

Revisions: Ser A
Description: The 1783-US4T1H is a switch with 4 Fast Ethernet RJ45 Ports, 1 Fast Ethernet Singlemode Preinstalled Fiber SFP Module SFP Ports, 1.69 A Max Inrush Current, and a 24V (12
Call
Request a quote for 1783-US4T1H

Description: The 1783-US4T1H is a switch with 4 Fast Ethernet RJ45 Ports, 1 Fast Ethernet Singlemode Preinstalled Fiber SFP Module SFP Ports, 1.69 A Max Inrush Current, and a 24V (12

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1783-US4T1H.
Exchange: Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.4 with 3 reviews

    Technical Specifications for 1783-US4T1H

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1783-US4T1H
Total Ports5
RJ45 Ports4 Fast Ethernet
SFP Ports1 Fast Ethernet Singlemode Preinstalled Fiber SFP Module
Max Inrush Current1.69 A
Power Input24 V (12-48 V DC, 18-30 V AC, 50/60 Hz), SELV
Max Power Consumption3.4 W
Nom CurrentDC 180 mA; AC 360 mA
Max CurrentDC 380 mA; AC 750 mA
Wire Size: Ground Connection2.5 mm2 (14 AWG) Copper Wire Suitable for 187 degree F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal
Wire Size: DC Power Connection4.5 x 5.0 in -lb (0.50 x 0.56 N - m)
Power Terminal Screw Torque8.05 in -lb
Max Ground Terminal Screw TorqueOpen-Style/None
Enclosure Type Rating4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm)
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1783-US4T1H
Total Ports5
RJ45 Ports4 Fast Ethernet
SFP Ports1 Fast Ethernet Singlemode Preinstalled Fiber SFP Module
Max Inrush Current1.69 A
Power Input24 V (12-48 V DC, 18-30 V AC, 50/60 Hz), SELV
Max Power Consumption3.4 W
Nom CurrentDC 180 mA; AC 360 mA
Max CurrentDC 380 mA; AC 750 mA
Wire Size: Ground Connection2.5 mm2 (14 AWG) Copper Wire Suitable for 187 degree F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal
Wire Size: DC Power Connection4.5 x 5.0 in -lb (0.50 x 0.56 N - m)
Power Terminal Screw Torque8.05 in -lb
Max Ground Terminal Screw TorqueOpen-Style/None
Enclosure Type Rating4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm)
s

About 1783-US4T1H

The 1783-US4T1H by world-class manufacturer Allen Bradley is an unmanaged industrial Ethernet switch used for networking. Using this switch increases the network’s elasticity and performance, and eases any network traffic problems in addition to having full protection.This switch has four (4) fast RJ45 Ethernet ports and one (1) fast SFT (Single-mode Fiber Pre-installed) Ethernet port giving it a total of five (5) ports. With flash memory (SD) and a compact design, this unit is made to maximize storage space.

This unit has an average temperature range that extends from -40 degrees Celsius to 70; its input voltage can range between 12 and 48 Volts DC or 18 to 30 Volts AC, at between 50 and 60 Hertz, and it can be mounted on a DIN-rail. Its Nominal AC/DC current is around 360/180 mA respectively, while its Maximum DC current is 380 mA, its Maximum AC current being 750 mA. At maximum, it consumes 3.4 Watts of power.

The 1783-US4T1H unit requires a specific type of wire with a size of 2.5 square millimeters (14 AWG) made of copper, which must be able to withstand temperatures up to 187 degrees Fahrenheit (86 degrees Celsius) for its ground connection. Its power terminal screw has a torque of 8.05 inches per pound, with an Open-Style ground terminal screw.

The 1783-US4T1H has reduced the problem of unwanted traffic by adding a protection system to control the unit’s daily traffic and make the network communication path more open. This type of switch also uses AOP (CIP) and real-time diagnostics to approach solutions to the presented problems. Adding power inputs can increase the input capacity and minimize time in harsh environments. This module meets the ROHS material restriction standards, increasing its durability and compatibility, and has dimensions of 4.51 x 3.02 x 1.17 inches (114.5 x 76.8 x 29.6 millimeters).

Repair Services for 1783-US4T1H

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 1783-US4T1H. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1783-US4T1H

Please refer to the manual for more information about the 1783-US4T1H such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
