Allen Bradley Display 6182H 6182H-10TRH4D

Product image is representative; revision or series may vary. Contact us to request a specific version.

6182H-10TRH4D

|
Need a Specific Revision?

The 6182H-10TRH4D from Allen Bradley serves as an operator interface terminal designed for effective interaction in automated systems. It features a 10-inch color active matrix TFT LCD display with a resolution of 640 x 480 pixels, paired with touchscreen input for user engagement.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 6182H-10TRH4D

ManufacturerAllen Bradley
Product TypeOperator Interface Terminal
Product LineDisplay 6182H
Part Number6182H-10TRH4D
Weight5.69 lbs (2.58 kg)
Communication ProtocolStandard Communication (Ethernet & RS-232)
Input TypeTouchscreen
Display Size10 inches
Resolution640 x 480 pixels
Rated Voltage24V DC nominal (18 to 32 V DC)
Display TypeColor Active Matrix TFT LCD
RAM Capacity128 MB
Flash Memory128 MB
Relative Humidity5 to 95% (Non-condensing)
Installation Height2000 m
Power TypeDC Power
View as PDF
Request a Repair

The Allen Bradley 6182H-10TRH4D is classified as an operator interface terminal, integrating advanced features for seamless human-machine interaction. Displaying critical information on a 10-inch screen, this terminal utilizes a color active matrix TFT LCD technology. The resolution of 640 x 480 pixels ensures clarity, which is essential for operators monitoring processes.

Input is facilitated through a responsive touchscreen, providing an intuitive approach to accessing and controlling system features. The nominal rated voltage for this unit is set at 24V DC, with acceptable input ranging between 18 to 32V DC, making it adaptable to various power setups.

Communication capabilities include standard Ethernet and RS-232 protocols, enhancing connectivity options for effective integration within control systems. This terminal is supported by a robust memory system, featuring both 128 MB of RAM and 128 MB of flash memory for application storage. Relative humidity tolerances span from 5% to 95% without condensation, which allows operation in a variety of environmental conditions.

Additionally, the 6182H-10TRH4D can be installed at an altitude of up to 2000 meters, making it suitable for diverse operational settings. Power for the terminal is provided via DC power, ensuring reliability and stable performance during use.

Revision Part #Also known as
6182H-10TRH4D Ser A6182H-10TRH4D/A, Series A, Rev A
Don't see your particular revision? Contact us now.
