6186-M15AL

Revisions: Ser A Ser B Ser C Ser D Ser E
Description: The 6186-M15AL industrial monitor is a VersaView series monitor from Allen-Bradley/Rockwell Automation. Its display screen is a TFT screen with color graphics that is 15 inches wide. Some of the VersaView series monitors support touchscreens, but the 6186-M15AL monitor does not. Its bezel is made out of aluminum. The 6186-M15AL monitor operates with an auto-ranging voltage range of 90 to 264 Volts AC at 47 to 63 Hertz line frequency.
Available Now
Request a quote for 6186-M15AL

Description: The 6186-M15AL industrial monitor is a VersaView series monitor from Allen-Bradley/Rockwell Automation. Its display screen is a TFT screen with color graphics that is 15 inches wide. Some of the VersaView series monitors support touchscreens, but the 6186-M15AL monitor does not. Its bezel is made out of aluminum. The 6186-M15AL monitor operates with an auto-ranging voltage range of 90 to 264 Volts AC at 47 to 63 Hertz line frequency.

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 6186-M15AL.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.8 with 18 reviews

    Technical Specifications for 6186-M15AL

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.6186-M15AL
Product Line1500M Industrial Monitor
Display Size 15 in.
Display ColorColor Active Matrix TFT
Input TypeExternal Input
Input Power90-264 VAC
Software 32 or 64 bit
Bezel TypeAluminum
BacklightCCFT tubes
Mounting Options Panel, Bench/Tabletop, and Rack Mount
Shipping Weight20 lbs.
Shipping Dimensions13 x 17 x 4 in.
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.6186-M15AL
Product Line1500M Industrial Monitor
Display Size 15 in.
Display ColorColor Active Matrix TFT
Input TypeExternal Input
Input Power90-264 VAC
Software 32 or 64 bit
Bezel TypeAluminum
BacklightCCFT tubes
Mounting Options Panel, Bench/Tabletop, and Rack Mount
Shipping Weight20 lbs.
Shipping Dimensions13 x 17 x 4 in.
s

About 6186-M15AL

The Allen-Bradley 6186-M15AL VersaView flat panel monitor does not have a touchscreen input. It runs on a voltage rating of 90-264V AC, auto ranging, at a maximum power consumption of 24 W, and 47-63 Hz. Its non-condensing relative ambient humidity is between 10 and 90%, its ideal operating temperature is between 5 and 50 oC, and its ideal non-operating temperature is between -20 and 60 oC. The 6186-M15AL uses an RGB analog video input signal for a video interface and its video bandwidth is 80 MHz. The 6186-M15AL monitor’s on-screen display menu allows you to configure its display resolution information, to power the monitor on or off, and to adjust the OSD timeout timer, the OSD lock and unlock, the contrast, the automatic screen setup, the manual color adjustment, and the horizontal or vertical position of the screen.







The display used on the 6186-M15AL monitor is a 16.7 million color active matrix TFT screen that has a contrast ratio of 500:1. Its display area is 12 x 9 inches and its display size measures 15 inches. This monitor is also backlit, specifically by 4 cold cathode tubes that have a typical luminance of 250 cd/ m2 (Nits) and an average life at half brightness of around 50,000 hours. Its native resolution is 1024 x 768. The 32 or 64-bit software and FactoryTalk View provide convenient interfaces and this monitor uses communication cables.



Technical Description of 6186-M15AL

Allen Bradley VersaView series Industrial Monitors with 15 in. Color Active Matrix TFT display, External input and 90-264 VAC input power

Repair Services for 6186-M15AL

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 6186-M15AL. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 6186-M15AL

Please refer to the manual for more information about the 6186-M15AL such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
6186-M15AL Ser A
6186-M15AL/A, Series A, Rev A Request Quote
6186-M15AL Ser B
6186-M15AL/B, Series B, Rev B Request Quote
6186-M15AL Ser C
6186-M15AL/C, Series C, Rev C Request Quote
6186-M15AL Ser D
6186-M15AL/D, Series D, Rev D Request Quote
6186-M15AL Ser E
6186-M15AL/E, Series E, Rev E Request Quote
Common misspellings:
  • 6l86-M15AL
  • 61b6-M15AL
  • 6186-Ml5AL
  • 6186-M15A1
  • 6186M15AL

Dimensions For 6186-M15AL

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 6186-M15AL

Resolutions For 6186-M15AL
