6177R-RMPW7

Available Now
Request a Quote
VersaView Non-Display series Terminals with 4GB DDR3 of RAM, also a 1 x 500 GB for storage and an input power of 100-240V AC
Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 6177R-RMPW7.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

phone

International
919-205-4392
Rated 4.5 with 11 reviews
top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

6177R-RMPW7

Revisions: Ser A
Description: VersaView Non-Display series Terminals with 4GB DDR3 of RAM, also a 1 x 500 GB for storage and an input power of 100-240V AC
Available Now
Request a quote for 6177R-RMPW7


top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 6177R-RMPW7.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.5 with 11 reviews

    Technical Specifications for 6177R-RMPW7

ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i3-2120 3.3 Ghz, Dual Core
RAM4GB DDR3
ModelPerformance
Input Power100-240V AC
Operating SystemWindows 7 Professional SP1
Memory1 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in
ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i3-2120 3.3 Ghz, Dual Core
RAM4GB DDR3
ModelPerformance
Input Power100-240V AC
Operating SystemWindows 7 Professional SP1
Memory1 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in

About 6177R-RMPW7

The Allen-Bradley 6177R-RMPW7 is a Non-Display Industrial Computer. This 1450R rack mountable non-display computer features an extremely powerful Intel i3-2120 3.3 GHz dual-core processor, speedy 4GB DDR3 RAM memory, and a large hard disk drive (500GB). It is designed for high performance, with low maintenance and full reliability. The 6177R-RMPW7 is supplied with 100 to 240 Volts of AC voltage. This is a RAID 0/1 capable Performance model, from the 1450R series running on Windows 7 Professional SP1 (64 bit) operating system. This non-display industrial computer’s communication capabilities are supported with 2 Ethernet 10/100/1000 ports, 2 serial ports, 4 USB 2.0 (rear) ports, 2 USB 2.0 (front) ports, 1 USB 2.0 (internal) port, 1 USB 3.0 (front) port, 1 USB 3.0 (rear) port, 1 eSATAp (rear port), 2 PS2 ports, 1 parallel port, an audio line out/in, and a microphone. The available video connectors that are one DVI-I and one DVI-D (VGA capable with included adapter). The expansion slots are 1 PCI Express x16, 1 PCI Express x4, 1 PCI Express x1, 4 PCI. This industrial computer is rack mountable, requiring 4U of rack space. The hard disk drives installed on this module can be hot-swapped and shock mounted, and have a 24/7 rating. The list of this module’s advanced features continues with integrated system backup/restoration capabilities and integrated system diagnostics. There are also three status indicators (power status, disk drive access status, and system health status) on the front panel, which help in this module’s diagnostics.

Rockwell Automation supports this non-display industrial computer with backup system images and drivers, which can be found on the Rockwell Automation Product Compatibility and Download Center. An industrial display should be combined with the 6177R-RMPW7 module to complete the industrial automated system. The Allen-Bradley 6177R-RMPW7 has shipping dimensions of 6.93 x 16.97 x 18.31 inches (176 x 431 x 465 millimeters). This item weighs approximately 30.8 pounds (13.97 kilograms) and operates at a temperature range of 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit).

Repair Services for 6177R-RMPW7

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 6177R-RMPW7. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 6177R-RMPW7

Please refer to the manual for more information about the 6177R-RMPW7 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
6177R-RMPW7 Ser A
6177R-RMPW7/A, Series A, Rev A Request Quote
Common misspellings:
  • 6l77R-RMPW7
  • 6177RRMPW7

Dimensions For 6177R-RMPW7

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 6177R-RMPW7

Resolutions For 6177R-RMPW7

Technical Specifications
ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i3-2120 3.3 Ghz, Dual Core
RAM4GB DDR3
ModelPerformance
Input Power100-240V AC
Operating SystemWindows 7 Professional SP1
Memory1 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in
ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i3-2120 3.3 Ghz, Dual Core
RAM4GB DDR3
ModelPerformance
Input Power100-240V AC
Operating SystemWindows 7 Professional SP1
Memory1 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in
About

The Allen-Bradley 6177R-RMPW7 is a Non-Display Industrial Computer. This 1450R rack mountable non-display computer features an extremely powerful Intel i3-2120 3.3 GHz dual-core processor, speedy 4GB DDR3 RAM memory, and a large hard disk drive (500GB). It is designed for high performance, with low maintenance and full reliability. The 6177R-RMPW7 is supplied with 100 to 240 Volts of AC voltage. This is a RAID 0/1 capable Performance model, from the 1450R series running on Windows 7 Professional SP1 (64 bit) operating system. This non-display industrial computer’s communication capabilities are supported with 2 Ethernet 10/100/1000 ports, 2 serial ports, 4 USB 2.0 (rear) ports, 2 USB 2.0 (front) ports, 1 USB 2.0 (internal) port, 1 USB 3.0 (front) port, 1 USB 3.0 (rear) port, 1 eSATAp (rear port), 2 PS2 ports, 1 parallel port, an audio line out/in, and a microphone. The available video connectors that are one DVI-I and one DVI-D (VGA capable with included adapter). The expansion slots are 1 PCI Express x16, 1 PCI Express x4, 1 PCI Express x1, 4 PCI. This industrial computer is rack mountable, requiring 4U of rack space. The hard disk drives installed on this module can be hot-swapped and shock mounted, and have a 24/7 rating. The list of this module’s advanced features continues with integrated system backup/restoration capabilities and integrated system diagnostics. There are also three status indicators (power status, disk drive access status, and system health status) on the front panel, which help in this module’s diagnostics.

Rockwell Automation supports this non-display industrial computer with backup system images and drivers, which can be found on the Rockwell Automation Product Compatibility and Download Center. An industrial display should be combined with the 6177R-RMPW7 module to complete the industrial automated system. The Allen-Bradley 6177R-RMPW7 has shipping dimensions of 6.93 x 16.97 x 18.31 inches (176 x 431 x 465 millimeters). This item weighs approximately 30.8 pounds (13.97 kilograms) and operates at a temperature range of 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit).

Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 6177R-RMPW7. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 6177R-RMPW7. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.
Revisions

Please refer to the manual for more information about the 6177R-RMPW7 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
6177R-RMPW7 Ser A
6177R-RMPW7/A, Series A, Rev A Request Quote

Common misspellings:
  • 6l77R-RMPW7
  • 6177RRMPW7
