6177R-RMSS8

Revisions: Ser A
Description: VersaView Non-Display series Terminals with 8GB DDR3 of RAM, also a 2 x 500 GB for storage and an input power of 100-240V AC
Call
Request a quote for 6177R-RMSS8

Description: VersaView Non-Display series Terminals with 8GB DDR3 of RAM, also a 2 x 500 GB for storage and an input power of 100-240V AC

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 6177R-RMSS8.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.9 with 3 reviews

    Technical Specifications for 6177R-RMSS8

ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i5-2400 3.1 GHz, Quad Core
RAM8GB DDR3
ModelServer
Input Power100-240V AC
Operating SystemWindows Server 2008 R2 SP1
Memory2 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in
ManufacturerRockwell Automation
BrandAllen-Bradley
ProcessorIntel i5-2400 3.1 GHz, Quad Core
RAM8GB DDR3
ModelServer
Input Power100-240V AC
Operating SystemWindows Server 2008 R2 SP1
Memory2 x 500 GB
Mount TypeRack Mount
Shipping Weight30.80 lb
Shipping Dimensions6.93 x 16.97 x 18.31 in
s

About 6177R-RMSS8

The Allen-Bradley 6177R-RMSS8 1450R Non-Display Industrial Computer is a server package, non-display industrial computer with an extremely powerful Intel Core processor, very large hard disk size, and fast DDR3 memory used for applications which need visualization, control, and information. The computer is a rack mount device, which can be used an Allen-Bradley Industrial Display device, and it comes with the Microsoft Windows Server 2008 R2 (64-bit) operating system. The 6177R-RMSS8 is designed with an Intel Core i5-2400 processor with 3.1 GHz processing speed and turbo boost of 3.4 GHz max, and it comes with 8 GB of DDR3 system memory. It also has double 500G SATA interfaced Hard Disk with a Redundant Array of Inexpensive Disks (RAID 1)-enabled option which increases performance and provides automatic protection against data loss from drive failure, and it comes with a Slim DVD-RW optical disc drive. The 6177R-RMSS8 has an Intel HD2000 Graphic controller with 1920 x 1200 video resolution, and it provides cooling using 2 Chassis fans and a heatsink fan.





The 6177R-RMSS8 comes with 4 PCI expansion slots, and it is equipped with 2 integral 10/100/1000 Mbps ports. The computer has 4 rear USB 2.0 ports, 1 front USB port, 1 internal USB 2.0 port for safe USB use, 20 Serial RS-232 ports, 1 parallel port, 1 rear USB 3.0 port, 1 eSATAp, 2 DVI port, and 1 PS/2 Mouse/Keyboard port. It is powered via an AC input line, with an input voltage range of 100 to 240V AC (auto-ranging) at 50/60Hz, and it has a maximum power consumption of 600W. It is built for industrial environments with an operating temperature range of 32 to 113 °F at 10 to 90% relative humidity, and a storage temperature range level of -4 to 140 °F. The 6177R-RMSS8 is designed to withstand a 15G operating shock for 11ms with a vibration of 1G peak at 57 to 640Hz, and its maximum Acoustic Noise is 64.4dB at 50cm. It is CE, c-UL-us, FCC, C-TICK, KCC, and RoHS certified, and it weighs approximately 14.0kg (30.80lb), with dimensions of 176mm x 431mm x 465mm (6.93in x 16.97in x 18.31in).



Repair Services for 6177R-RMSS8

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote
Our highly skilled technicians can repair your 6177R-RMSS8. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 6177R-RMSS8

Please refer to the manual for more information about the 6177R-RMSS8 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
6177R-RMSS8 Ser A
6177R-RMSS8/A, Series A, Rev A Request Quote
