6181P-12NSXP

The 6181P-12NSXP VersaView 1200P Standard Integrated Display Computer by Allen-Bradley is a DC-powered industrial computer with an integrated display. The computer features an Intel Celeron M423 Processor, with 1.06 GHz processing speed, and a 1M, L2 cache memory. It comes with the dual-channel DDR2 system memory slot with a 512MB DDR2 RAM installed, and it also has 40GB SATA hard disk drive, installed on its single bootable compact flash slot. Unlike the performance range, the 6181P-12NSXP does not come with an expansion slot, and it does not support DVD-RW/CD-RW drive. It has a built-in single serial COM port, 4 USB ports, an audio line in/line out, a microphone slot, and a 2GB (RJ45) Ethernet LAN port for network connectivity. It provides visualization and control via 12-inch active matrix flat display with 800 x 600 resolution in 256K colors, and 246mm x 185mm (9.7in x 7.3in) display dimensions.

It has a DC power supply, with a supply voltage of 20V DC, with a net power consumption of 65W at 3.25A, and 20V DC, and it dissipates 65W (222 BTU/h) heat when operational. The 6181P-12NSXP’s operating temperature range is 0-55 oC (32-131 oF), at 10-90% non-condensing relative humidity, and the machine can be stored at a temperature range of -20-60 oC (-4-140 oF). The 6181P-12NSXP has a maximum operating altitude of 2,000meters (6,561 feet) without de-rating and it is built to withstand a 15G operating shock, with a vibration of 1G at 57-640Hz. it weighs around 7.85kg (17.31lb), with a net area of 279mm x 349mm x 99mm (10.98in x 13.74in x 3.91in), and it has c-UL-us, CE, C-TICK, and RoHS certification.
