The Allen-Bradley 2706-B11C8 is a Dataliner DL20 message display. It has a Vacuum Fluorescent Display (VFD) with a dimension of 14.4 x 14.4 inches. It is available in a one-line configuration with a parallel port and can display up to 20 characters per line. It has 8 KB RAM and 110 to 120 Volts AC input power. The 2706-B11C8 Message Display is designed to receive slave addresses, message triggers, and variable data from an SLC or PLC module. For communication, it has an RS-422 port for file transfer and an RS-232 port for uploading and downloading files. It displays a wide variety of symbols and characters readable at up to 30 feet away. The 2706-B11C8 supports offline programming software to create and edit application files. It is mounted in a panel or encloser with a NEMA Type 12,13 rating.
The 2706-B11C8 Message Display has various capabilities such as dynamic message chaining, invisible messages, and data trigger modes. Parallel data lines allow it to accept 5 to 30 Volts DC and 120 Volts AC input signals. It performs self-testing and diagnostics during power on and has autorun features. Messages can be configured or entered manually by attaching an external keyboard, CRT monitor, or any extra terminal. The 2706-B11C8 has a real-time clock that keeps the current date and time. It can also create a backup and record the occurrence and sequence of messages. External devices such as printers, slave displays, and alarms can be connected as required. The 2706-B11C8 Message Display is highly customizable and capable of effectively delivering alarms and messages in an industrial environment.
FAQ for 2706-B11C8
The Allen Bradley DataLiner Message Display offer the hardware and customization needed for effective factory-wide display. The DataLiner family features the DL5, DL10, DL20, DL30, DL40, DL40P, and DL50 marquee product lines. These products feature Vacuum Fluorescent, Red, or Tri-Color displays with from 1 to 5 lines of characters. There are parallel ports that provide both RS-232 and RS-485 communication. DataLiners allow for viewing of messages up to 240 feet away. These highly compatible and customizable message displays effectively deliver messages and alarms across the warehouse floors.
Repair Services for 2706-B11C8
||Ask|| Get Quote |
Our highly skilled technicians can repair your 2706-B11C8. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.
Revisions for 2706-B11C8
Please refer to the manual for more information about the 2706-B11C8 such as the wiring diagrams, data sheets,
firmware information and migration or obsolescence details.
