2706-B13C16

Description: DL20 series Message Display with 1 line, 20 character VFD and 110/120V AC input power and 16K RAM memory
Available Now
Request a quote for 2706-B13C16

Description:

DL20 series Message Display with 1 line, 20 character VFD and 110/120V AC input power and 16K RAM memory



no auth
no auth mobile
disclaimer
credit cards
better business bureau
Revisions: -Manual -Price -Ser A -Ser B -Ser C -Ser D -Ser E -Ser F A B C D E F G H I J

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 2706-B13C16.
Exchange: Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

phone

International
919-205-4392
phone

International
919-205-4392

Rated 4.7 with 5 reviews


About 2706-B13C16

The Allen-Bradley 2706-B13C16 terminal is a Dataliner DL20 message display terminal that has a Vacuum Fluorescent Display (VFD) screen that measures 14.4 x 14.4 inches. It is available in a 1-line configuration with a parallel port and it can display up to 20 characters per line. It also has 16 KB of RAM and a 110 to 120 Volts AC input power range. The 2706-B13C16 message display terminal is designed to receive slave addresses, message triggers, and variable data from an SLC or PLC module. For communication, it has an RS-422 port for file transfer and an RS-232 port for file upload and download. It displays a wide variety of symbols and characters that are readable at up to 30 feet away. The 2706-B13C16 terminal supports offline programming software to create and edit application files.

The Allen-Bradley 2706-B13C16 message display terminal has capabilities that include dynamic message chaining, invisible messages, and data trigger modes. Parallel data lines allow it to accept 5 to 30 Volts DC and 120 Volts AC input signals. It performs diagnostics during the power-on process and it has autorun features. Messages can be configured or entered manually by attaching an external keyboard, a CRT monitor, or an extra terminal. It has a real-time clock that tells the current date and time. It can also create a backup and record the occurrence and sequence of messages. External devices such as printers, slave displays, and alarms can be connected. The 2706-B13C16 message display terminal is highly customizable and it can effectively deliver alarms and messages in an industrial environment.


Technical specifications:


ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2706-B13C16
Product LineDL20
Display Size14.4 x 14.4 inches
Display ColorVacuum Fluorescent Display (VFD)
Input TypeASCII
Communication RS-422 and RS-232
Input Power110 to 120 Volts AC
Memory16K RAM
Enclosure TypeNEMA Type 12/13
Line Count1
Character Count20
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2706-B13C16
Product LineDL20
Display Size14.4 x 14.4 inches
Display ColorVacuum Fluorescent Display (VFD)
Input TypeASCII
Communication RS-422 and RS-232
Input Power110 to 120 Volts AC
Memory16K RAM
Enclosure TypeNEMA Type 12/13
Line Count1
Character Count20

FAQ

The Allen Bradley DataLiner Message Display offer the hardware and customization needed for effective factory-wide display. The DataLiner family features the DL5, DL10, DL20, DL30, DL40, DL40P, and DL50 marquee product lines. These products feature Vacuum Fluorescent, Red, or Tri-Color displays with from 1 to 5 lines of characters. There are parallel ports that provide both RS-232 and RS-485 communication. DataLiners allow for viewing of messages up to 240 feet away. These highly compatible and customizable message displays effectively deliver messages and alarms across the warehouse floors.

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 2706-B13C16. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Please refer to the manual for more information about the 2706-B13C16 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.
