The 2706-B43J31 DL20 data liner display terminal by Allen-Bradley is an interactive display terminal in the DL20 data liner series with a four-line display and a RAM of 31KB. It has 20 uppercase and lowercase symbols per line with a character height of 12.7 millimeters (0.5 inches) in a four-line display and a vacuum fluorescent dot matrix display which can be seen clearly from 7.6 meters (25 feet) away. The 2706-B43J31 has an input voltage range between 85 and 264 Volts AC at 47 to 63 Hertz and a maximum power rating of 45VA at 85 Volts AC. It is fitted with an MDL or GMC fuse with a protection rating of 1.25 Amps, 250 Volts AC (USA) and 1.5 Amps, 250 Volts AC (Europe).
The 2706-B43J31 can be programmed offline with a PC-compatible computer or a programming keyboard, connected through the RS-232 and RS-422 serial communication ports using a Menu-Drive offline programming package. It also has a parallel port with 10 data input lines and 2 strobe inputs and a data input voltage range of 5 to 30 Volts DC or 110 to 120 Volts AC using an AC converter. The 2706-B43J31 DL20 data liner display terminal has a Lithium battery-backed RAM with 31 KB for message memory. It has an operational temperature range between 0 and 60 degrees Celsius (32 and 140 degrees Fahrenheit) and a storage temperature range between -40 and 85 degrees Celsius (-40 and 185 degrees Fahrenheit) at 5 to 95% non-condensing relative humidity. It weighs approximately 5.4 kilograms (12 pounds) and has dimensions of 157 x 366 x 188 millimeters (6.2 x 14.4 x 7.4 inches).
FAQ for 2706-B43J31
The Allen Bradley DataLiner Message Display offer the hardware and customization needed for effective factory-wide display. The DataLiner family features the DL5, DL10, DL20, DL30, DL40, DL40P, and DL50 marquee product lines. These products feature Vacuum Fluorescent, Red, or Tri-Color displays with from 1 to 5 lines of characters. There are parallel ports that provide both RS-232 and RS-485 communication. DataLiners allow for viewing of messages up to 240 feet away. These highly compatible and customizable message displays effectively deliver messages and alarms across the warehouse floors.
Repair Services for 2706-B43J31
