The 2706-C11J32 DL30 message display by Allen-Bradley is an electronic display device with a Vacuum Fluorescent Display (VFD) and 0.33-inch-long characters which remain visible at a maximum viewing distance of 4.6 meters (15 feet). It has a display module with up to 16 alphabetical, numerical, punctuation, and symbol characters. The letters are uppercase only. It has a power supply module with an AC rating of 120 Volts and 45VA maximum apparent power with an MDL fuse with a circuit rating of 250 Volts AC and 1.2 Amps. Messages of varying length can be stored in the 32KB EEPROM with a maximum of 1022 message blocks.
The 2706-C11J32 is programmed offline using the 2706–NP1 or 2706–NP1 offline programming software through either IBM PC–AT, Allen Bradley T50, 6120, or 6121 industrial computers connected to it through an RS-232 and RS-422 serial communication port. The RS-232 serial port is also used for easy connection to external peripheral devices like printers and keyboards. The parallel port of the 2706-C11J32 has 16 input data lines and 2 strobe lines, which allows for easy triggering of the messages on display, and the selection between the serial port and the parallel port is achieved via the configured DIP switch. The 2706-C11J32 functions best at 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) and a 5 to 95% relative humidity bracket without condensation. It has a NEMA 12, and 13 rating, it weighs 1.70 kilograms (3.75 pounds) and measures 4.5 x 9.4 x 5 inches.
FAQ for 2706-C11J32
The Allen Bradley DataLiner Message Display offer the hardware and customization needed for effective factory-wide display. The DataLiner family features the DL5, DL10, DL20, DL30, DL40, DL40P, and DL50 marquee product lines. These products feature Vacuum Fluorescent, Red, or Tri-Color displays with from 1 to 5 lines of characters. There are parallel ports that provide both RS-232 and RS-485 communication. DataLiners allow for viewing of messages up to 240 feet away. These highly compatible and customizable message displays effectively deliver messages and alarms across the warehouse floors.
Repair Services for 2706-C11J32
||Ask|| Get Quote |
Our highly skilled technicians can repair your 2706-C11J32. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.
Revisions for 2706-C11J32
Please refer to the manual for more information about the 2706-C11J32 such as the wiring diagrams, data sheets,
firmware information and migration or obsolescence details.
