The Allen Bradley DTAM plus Operator Interface Module number 2707-L40P2 is a versatile programmable Human Machine Interface (HMI) suitable to interface simple processes or machinery operation to operators.
The DTAM PLUS 2707-L40P2 features a keypad with 4 lines of 20 characters each, a 1 x 3 inch LCD screen, and an adjustable LED (yellow) backlighting system, along with a hardened, multicolor, durable keypad, that contains multiple LED indicators to stimulate operator attention when needed. It has an input type of ASCII and is powered by 110 to 300 Volts of DC power.
The DTAM PLUS 2707-L40P2 can be programmed through PC parallel port using the MS® DOS™ based DTAM Programming Software (DPS), where a user can create and load fully customized “Application Screens” for this unit’s display. It contains a 40K nonvolatile memory that stores display configurations and Operating Systems, and can be loaded up with maximum 244 “Application Screens” and is provided with a Real Time Clock to time stamp critical data and reports.
This 2707-L40P2 model contains various types of “Application Screens” that can fulfill the requirements of most applications and can even help a user to cut the cost and complexity of installing a dedicated Alarm or Bar Graph indicator. Screen types that are available include “Menu” and “Sub-Menu” Screens, Security Screens, Data Display Screens, Data Entry Screens, Recipe Screens, Bargraph Screens and Alarm Screens.
This unit is provided with a serial port that can be configured to either the point to point RS323 or the multidrop RS485 functionalities through a DIP switch. The RS232/RS485 port can be used to connect the 2707-L40P2 to PLC-5, SLC Controller (5/03, 5/04, 5/05) or the MicroLogix 1000 using the DF1 protocol.
FAQ for 2707-L40P2
The Allen Bradley DTAM Plus displays are ideal for broadband communication over the factory and warehouse floor. It features a RS-232C, RS-485 port which allows it to interface with Allen-Bradley PLC and SLC controller product lines. The Point-Access Function provides a way to monitor and revise data files in SLC or PLC controllers.The DTAM Micro allows for easy modification of data blocks with its recipe type functions. It also has a 1.0 x 3.0 LCD (Yellow LED) Display and a 40K memory capatability.
Repair Services for 2707-L40P2
||$743||Add to Cart |
Our highly skilled technicians can repair your 2707-L40P2. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.
Revisions for 2707-L40P2
Please refer to the manual for more information about the 2707-L40P2 such as the wiring diagrams, data sheets,
firmware information and migration or obsolescence details.
|Revision Part #
||Also Known as
||2707-L40P2/A, Series A, Rev A
||2707-L40P2/B, Series B, Rev B
||2707-L40P2/C, Series C, Rev C
||2707-L40P2/D, Series D, Rev D
||2707-L40P2/X, Series X, Rev X
The 2707-L40P2 has several firmware revisions: 2707-L40P2 FRN 1.00, 2707-L40P2 FRN 1.01, and 2707-L40P2 FRN 1.02
