2711-T14C8

Description: The 2711-T14C8 operator interface terminal has been manufactured as part of the Panelview 1400 series by Allen-Bradley/Rockwell Automation. It can support color graphics on its touch and display screen. The screen on the 2711-T14C8 operator interface terminal is 14 inches wide. It uses AC power and it supports the DH+ industrial communication network. The 2711-T14C8 operator interface terminal also supports connection to a printer through its RS-232 printer port.
In Stock Ships Today
Request a quote for 2711-T14C8

About | Products Specs | FAQ

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty.

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 2711-T14C8.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

mobile

Phone
1-919-205-4392
phone

International
1-919-205-4392

Email
sales@dosupply.com

Rated 5 with 10 reviews

Technical Specifications for 2711-T14C8

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711-T14C8
Power TypeAC
Supply Voltage Limit85-264 Volts; 43-63 Hertz
Power Consumption200 VA max
Comm PortDH+
Total Application Flash Memory1008 Kbytes
Operating Shock15 g
Non-Operating Shock30 g
Operating Temperature32-131 F (0-55 C)
Dimensions13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm)
Display Dimensions10.0 x 7.5 in (255 x 191 mm)
Weight43.2 lbs (19.6 kg)
Operator InputTouchscreen
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 2711-T14C8 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-T14C8 units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711-T14C8
Power TypeAC
Supply Voltage Limit85-264 Volts; 43-63 Hertz
Power Consumption200 VA max
Comm PortDH+
Total Application Flash Memory1008 Kbytes
Operating Shock15 g
Non-Operating Shock30 g
Operating Temperature32-131 F (0-55 C)
Dimensions13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm)
Display Dimensions10.0 x 7.5 in (255 x 191 mm)
Weight43.2 lbs (19.6 kg)
Operator InputTouchscreen
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 2711-T14C8 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-T14C8 units instead of migration.


About 2711-T14C8

The Allen-Bradley 2711-T14C8 is a PanelView standard 1400 terminal with a touchscreen display. The terminal features a Color CRT screen measuring 14 inches and with an 800 x 600-pixel resolution. The screen is made up of 384 touch cells that fill up 16 rows and 24 columns, with each touch cell measuring 33 x 37 pixels. The 2711-T14C8 terminal has two communication ports available: a DH+ communication port and an RS-232 printer port. It also comes with a 1008-KB total application flash memory and status indicators you can use to check on the terminal's current condition. The entire terminal weighs 43.2 pounds and measures 13.97 x 17.37 x 15.53 inches. A NEMA Type 12/13 or 4x enclosure that is for indoor use only houses this terminal.

The terminal's operating temperature range is 0 to 55 degrees Celsius and with a storage temperature range of -40 to 85 degrees Celsius. It has a maximum power consumption of 200 VA and supply power limits of 43 to 63 Hertz and 85 to 264 Volts AC. It has a non-condensing relative humidity of 5 to 95% at 0 to 55 degrees Celsius and a heat dissipation of 78 W or 264 BTU/hour. The terminal also has an operating vibration of 1g at up to 2000 Hertz, an operating shock of 15g, and a non-operating shock of 30g.

FAQ for 2711-T14C8

Is the 2711-T14C8 a current model?


No, the 2711-T14C8 PanelView 1400 Color Terminal is discontinued. However, this terminal is available for purchase here, at DO Supply.

What is the operator input type for the 2711-T14C8?


The 2711-T14C8 PanelView 1400 Color Terminal has a touch screen operator input.

Does the 2711-T14C8 have any built-in communication ports?


Yes, the 2711-T14C8 PanelView 1400 Color Terminal has a built-in DH+ communication port.

What is the price of a 2711-T14C8 PanelView 1400 Color Terminal?


Submit a quote request, send us an email, or call 800-730-0292 for our best price.

Does DO Supply offer repair services for the 2711-T14C8 PanelView 1400 Color Terminal?


Yes, DO Supply offers repair services for a variety of Allen-Bradley products, such as the 2711-T14C8. For more information or to request a repair quote, please click here.

Technical Description of 2711-T14C8

DH+ Communication and RS-232 Printer Port

Repair Services for 2711-T14C8

Type Lead Time Price Action
Repair Service 2-4 weeks $1760cartAdd to Cart

Our highly skilled technicians can repair your 2711-T14C8. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 2711-T14C8

Please refer to the manual for more information about the 2711-T14C8 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
2711-T14C8 Ser A
2711-T14C8/A, Series A, Rev A Request Quote
2711-T14C8 Ser B
2711-T14C8/B, Series B, Rev B Request Quote
2711-T14C8X
2711-T14C8/X, Series X, Rev X Request Quote
Common misspellings:
  • 27l1-T14C8
  • 271l-T14C8
  • 2711-Tl4C8
  • 2711-T1AC8
  • 2711-T14Cb
  • 2711T14C8

Dimensions For 2711-T14C8

Size 14 inch
Input Type Touch
Panel Cutout Height 305 mm (12.0 in)
Panel Cutout Width 391 mm (15.40 in)
Terminal Height 355 mm (13.97 in)
Terminal Width 441 mm (17.37 in)
Terminal Overall Depth 394 mm (15.53 in)
Terminal Mounted Depth 370 mm (14.58 in)

Dimensions For 2711-T14C8

Resolutions For 2711-T14C8

Size 14 inch
Input Type Touch
Display Resolution 800 x 600
About

Technical Specifications for 2711-T14C8

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711-T14C8
Power TypeAC
Supply Voltage Limit85-264 Volts; 43-63 Hertz
Power Consumption200 VA max
Comm PortDH+
Total Application Flash Memory1008 Kbytes
Operating Shock15 g
Non-Operating Shock30 g
Operating Temperature32-131 F (0-55 C)
Dimensions13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm)
Display Dimensions10.0 x 7.5 in (255 x 191 mm)
Weight43.2 lbs (19.6 kg)
Operator InputTouchscreen
Product Lifecycle Status*Discontinued/Obsolete
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2711-T14C8
Power TypeAC
Supply Voltage Limit85-264 Volts; 43-63 Hertz
Power Consumption200 VA max
Comm PortDH+
Total Application Flash Memory1008 Kbytes
Operating Shock15 g
Non-Operating Shock30 g
Operating Temperature32-131 F (0-55 C)
Dimensions13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm)
Display Dimensions10.0 x 7.5 in (255 x 191 mm)
Weight43.2 lbs (19.6 kg)
Operator InputTouchscreen
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 2711-T14C8 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-T14C8 units instead of migration.

About 2711-T14C8

The Allen-Bradley 2711-T14C8 is a PanelView standard 1400 terminal with a touchscreen display. The terminal features a Color CRT screen measuring 14 inches and with an 800 x 600-pixel resolution. The screen is made up of 384 touch cells that fill up 16 rows and 24 columns, with each touch cell measuring 33 x 37 pixels. The 2711-T14C8 terminal has two communication ports available: a DH+ communication port and an RS-232 printer port. It also comes with a 1008-KB total application flash memory and status indicators you can use to check on the terminal's current condition. The entire terminal weighs 43.2 pounds and measures 13.97 x 17.37 x 15.53 inches. A NEMA Type 12/13 or 4x enclosure that is for indoor use only houses this terminal.

The terminal's operating temperature range is 0 to 55 degrees Celsius and with a storage temperature range of -40 to 85 degrees Celsius. It has a maximum power consumption of 200 VA and supply power limits of 43 to 63 Hertz and 85 to 264 Volts AC. It has a non-condensing relative humidity of 5 to 95% at 0 to 55 degrees Celsius and a heat dissipation of 78 W or 264 BTU/hour. The terminal also has an operating vibration of 1g at up to 2000 Hertz, an operating shock of 15g, and a non-operating shock of 30g.

FAQ for 2711-T14C8

Is the 2711-T14C8 a current model?


No, the 2711-T14C8 PanelView 1400 Color Terminal is discontinued. However, this terminal is available for purchase here, at DO Supply.

What is the operator input type for the 2711-T14C8?


The 2711-T14C8 PanelView 1400 Color Terminal has a touch screen operator input.

Does the 2711-T14C8 have any built-in communication ports?


Yes, the 2711-T14C8 PanelView 1400 Color Terminal has a built-in DH+ communication port.

What is the price of a 2711-T14C8 PanelView 1400 Color Terminal?


Submit a quote request, send us an email, or call 800-730-0292 for our best price.

Does DO Supply offer repair services for the 2711-T14C8 PanelView 1400 Color Terminal?


Yes, DO Supply offers repair services for a variety of Allen-Bradley products, such as the 2711-T14C8. For more information or to request a repair quote, please click here.

Technical Description of 2711-T14C8

DH+ Communication and RS-232 Printer Port
Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks $1760cartAdd to Cart

Our highly skilled technicians can repair your 2711-T14C8. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks $1760cartAdd to Cart

Our highly skilled technicians can repair your 2711-T14C8. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions

Please refer to the manual for more information about the 2711-T14C8 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
2711-T14C8 Ser A
2711-T14C8/A, Series A, Rev A Request Quote
2711-T14C8 Ser B
2711-T14C8/B, Series B, Rev B Request Quote
2711-T14C8X
2711-T14C8/X, Series X, Rev X Request Quote

Common misspellings:
  • 27l1-T14C8
  • 271l-T14C8
  • 2711-Tl4C8
  • 2711-T1AC8
  • 2711-T14Cb
  • 2711T14C8
PDF
2711-T14C8 PDF
Dimensions

Dimension For 2711-T14C8

Size 14 inch
Input Type Touch
Panel Cutout Height 305 mm (12.0 in)
Panel Cutout Width 391 mm (15.40 in)
Terminal Height 355 mm (13.97 in)
Terminal Width 441 mm (17.37 in)
Terminal Overall Depth 394 mm (15.53 in)
Terminal Mounted Depth 370 mm (14.58 in)
Resolutions

Resolutions For 2711-T14C8

Size 14 inch
Input Type Touch
Display Resolution 800 x 600
