Allen Bradley Panelview 2711E 2711E-T10C7X

Product image is representative; revision or series may vary. Contact us to request a specific version.

2711E-T10C7X

|
Need a Specific Revision?

The 2711E-T10C7X is a touch-enabled HMI terminal from Allen Bradley's PanelView 2711E series. This model features a 10.4-inch TFT display with a resolution of 640 x 480 pixels and supports up to 256 fixed colors for clear visualization.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 2711E-T10C7X

ManufacturerAllen Bradley
Product TypeTouch HMI terminal
Product LinePanelview 2711E
Part Number2711E-T10C7X
Weight11.56 lbs (5.24 kg)
Display10.4″ TFT, 640×480
Colors256 fixed colors
Touch Input40×40 px cells, up to 192 cells, ~1M presses
BacklightReplaceable, ~10k hours
Memory2.25 MB flash, PCMCIA expandable
Power90–132 / 180–264 VAC, 47–63 Hz, ~45 W
NetworksDH+, ControlNet, Remote I/O
TagsUp to 5,000
TransfersFile/block transfers supported
Serial PortRS-232, 300–19,200 baud
Alarm RelayForm-C, 24 V, 1 A
Temperature Range0–50 °C (operating), −25–60 °C (storage)
Shock/Vibration15 g operating, 30 g non-operating, 2 g vibration
View as PDF
Request a Repair

The Allen Bradley 2711E-T10C7X serves as a touch HMI terminal, facilitating user interactions with its intuitive interface. Featuring a 10.4-inch TFT screen, this device displays graphics at a resolution of 640 x 480 pixels, while supporting a palette of 256 fixed colors. The device incorporates a touch input system designed with 40×40 pixel cells, which can register up to 192 interactive cells and approximately 1 million presses over its lifespan.

To ensure visibility over extended periods, the terminal comes with a replaceable backlight estimated to last around 10,000 hours. Power supply options range from 90 to 132 VAC and 180 to 264 VAC, operating at 47 to 63 Hz, with an average consumption of 45 watts.

Communication capabilities are robust, with support for popular network protocols such as DH+, ControlNet, and Remote I/O. The terminal allows for tagging of up to 5,000 individual items, providing extensive data management capabilities. Additionally, it supports file and block transfers for data movement and configuration.

On the connectivity front, the terminal features an RS-232 serial port supporting baud rates from 300 to 19,200. It includes a Form-C alarm relay rated at 24 V and 1 A, enhancing its application in alarm management. The unit is designed to operate within a temperature range of 0 to 50 °C and can be safely stored at lower temperatures down to -25 °C and as high as 60 °C. With a weight of around 5.1 kg, it accommodates various mounting options. Furthermore, it is built to withstand shocks of 15 g during operation and 30 g in non-operational states, along with 2 g of vibration, ensuring durability for industrial environments.
