Product image is representative; revision or series may vary. Contact us to request a specific version.
2711P-T7C4D7
The Allen-Bradley 2711P-T7C4D7 terminal is a DC-powered operator interface terminal. It has been manufactured as part of the Allen-Bradley Panelview Plus 700 series of interface terminals. The 2711P-T7C4D7 operator interface terminal has a nominal voltage rating of 24 Volts DC and an input voltage rating of 18 to 30 Volts DC. It features a logic module, an RS-232 communication port, an Ethernet communication port, and a touchscreen with color graphics. The 2711P-T7C4D7 operator interface terminal operates at 0 to 55 degrees Celsius and it can be stored at -25 to 70 degrees Celsius.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for 2711P-T7C4D7
| Manufacturer | Allen Bradley |
|---|---|
| Category | Panelviews |
| Product Line | Panelview Plus 700 |
| Part Number | 2711P-T7C4D7 |
| UPC | 612598349708 |
| Weight | 4.44 lbs (2.01 kg) |
| Display Size | 6.5 in. |
| Display Color | Color |
| Input Type | Touchscreen |
| Communication | Ethernet and RS-232 |
| Input Power | 18-32 VDC |
| Memory | 256 MB |
| Backlight | 2711P-RL7C2 |
| Communication Cable | 1761-NET-ENI |
| Series | Series A, B, C, D, E, F, G |
| Product Lifecycle Status* | Discontinued/Obsolete |
* The Allen Bradley 2711P-T7C4D7 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711P-T7C4D7 units instead of migration.
The discontinued Allen Bradley Panelview Plus 700 2711P-T7C4D7 is an operator terminal that enables the user to interface with their machine. This HMI has a 6.5 in. Color Display. The user is able to control the HMI using the Touchscreen to input information and data. This unit is powered using 18-32 VDC power. This unit has the following internal memory: 256 MB. If applicable this unit has an internal backlight replacement part number of 2711P-RL7C2. The approximate shipping weight and dimensions are 8 lbs. and 14 x 11 x 8 in. EtherNet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an EtherNet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The EtherNet/IP screen displays and allows the user to modify some of the EtherNet/IP communication settings for a PanelView terminal. The 2711P-RN20 Ethernet communication module is available for the 700 to 1500 terminals if another Ethernet port is required. The module has its own unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and supports MDI/MDI-X connections. The parameters are downloaded with the application.
| Revision Part # | Also known as | |
|---|---|---|
| 2711P-T7C4D7 Ser A | 2711P-T7C4D7/A, Series A, Rev A | |
| 2711P-T7C4D7X | 2711P-T7C4D7/X, Series X, Rev X | |
| Don't see your particular revision? Contact us now. | ||
- 2711P-T7CAD7
- 2711PT7C4D7
- 2711PT7CAD7
- 271IP-T7C4D7
- 271IPT7C4D7
- 27I1P-T7C4D7
- 27I1PT7C4D7
- 27IIP-T7C4D7
- 27IIP-T7CAD7
- 27IIPT7C4D7
- 27IIPT7CAD7
Panelview Plus 700 Touchscreen 6.5 in Color Display Ethernet, RS-232, and two USB DC Power CE Logic Module with 256 MB
| Size | 6.5 inch (700 color) |
|---|---|
| Input Type | Keypad/ Touch |
| Display Type | Color active-matrix TFT |
| Display Size (Diagonal) | 6.5 in. |
| Viewing Area | 132 x 99 mm (5.2 x 3.9 in.) |
| Display Resolution | 640 x 480, 18-bit color graphics |
| Typical Brightness | 300 cd/m2 (Nits) |
