UD77
The UD77 from Control Techniques is a DeviceNet Interface Option Module tailored for the Unidrive series. It supports up to 64 nodes in a single network and facilitates robust communication via an RS485 port.
-
We sell industrial automation parts backed by our 2-year DO Supply Warranty.
-
Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
-
Repair and exchange services for all existing automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for UD77
| Manufacturer | Control Techniques |
|---|---|
| Series | Unidrive |
| Part Number | UD77 |
| Name of Module | DeviceNet Interface Option Module |
| Max. Number of Nodes | 64 nodes per network |
| Ambient Operating Temperature | 0 to 60 °C |
| Ambient Storage Temperature | -25 to 70 °C |
| Operating Humidity | 10 to 95 % RH (no condensation) |
| Storage Humidity | 5 to 95 % RH (no condensation) |
| Communication Port | RS485 |
| Communication Data Rate | 125 Kbits/sec to 500 Kbits/sec |
| Communication Type | Controller Area Network (CAN) |
| Max. Network Length | 500m at 125 kbits/sec, 100m at 500 kbits/sec |
| Compatibility | Unidrive Classic |
| PC Programming Port | RS232 |
| Max. Data Bytes | 6 data bytes per node |
| Weight | 0.18 kg (0.4 lbs) |
Control Techniques' UD77 module serves as a DeviceNet Interface Option for the Unidrive series. Capable of managing up to 64 nodes on a network, this component is ideal for enhancing communication within automation setups. The module operates effectively within an ambient temperature range of 0 to 60 °C, ensuring reliability in various environments. Temperature storage could extend from -25 to 70 °C, providing flexibility for varied operational conditions.
Humidity tolerances are a notable feature; while operating, the UD77 can handle relative humidity levels from 10% to 95% without condensation. During storage, it can withstand conditions ranging from 5% to 95% RH.
The communication interface utilizes an RS485 port, enabling data transfer rates between 125 and 500 Kbits/sec. Given its reliance on Controller Area Network (CAN) protocols, the UD77 ensures effective data handling across connected devices. The maximum network length can reach up to 500 meters at 125 kbits/sec, reducing to 100 meters at 500 kbits/sec, which accommodates diverse application needs.
Furthermore, this module is compatible with the Unidrive Classic series, allowing straightforward integration. It also features an RS232 port for PC programming, enhancing the user's capacity to configure and manage settings. Each node can manage up to 6 data bytes to optimize data exchange. The UD77 is lightweight, weighing just 0.18 kg or 0.4 lbs, facilitating easy installation and integration into various setups.
