DVT 535C
The DVT 535C from DVT Cognex is a highly efficient vision sensor designed to capture high-quality images. With a resolution of 640 × 480 pixels, it operates at a frame rate of 60 frames per second, ensuring smooth image capture.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for DVT 535C
| Manufacturer | DVT Cognex Vision |
|---|---|
| Product Type | Vision Sensor |
| Product Line | DVT Cognex |
| Part Number | DVT 535C |
| Image Sensor | CCD |
| Frame Rate | 60 fps |
| Shutter Type | Electronic |
| Ethernet | RJ-45 |
| Resolution | 640 × 480 px |
| RAM | 256 MB |
| Current Consumption | 300 mA |
| Mounting | 4 × M4 threaded holes |
| Image Type | Color |
| Lens | Telecentric / standard |
| Power Supply | 24 V DC |
| Digital I/O | 8 configurable |
| Flash Memory | 64 MB |
| Power Consumption | 5 W (base) |
Representing the DVT Cognex series, the DVT 535C is a specialized vision sensor designed to enhance imaging tasks in various applications. It is equipped with a CCD image sensor that provides clarity at a resolution of 640 × 480 pixels. Capturing images at a rapid frame rate of 60 frames per second, this unit ensures detailed image acquisition. The electronic shutter mechanism allows for accurate timing settings essential for high-speed applications.
This sensor utilizes an RJ-45 Ethernet interface allowing for straightforward network integration. It is designed for versatility with configurable digital connections, offering up to 8 I/O configurations. The device runs on a power supply of 24 V DC while consuming an efficient 5 watts at base operation. Current consumption is rated at 300 mA.
For mounting, the sensor includes four M4 threaded holes, ensuring secure and stable installation in varying environments. Users can choose between telecentric and standard lenses, adapting to specific imaging requirements. Additionally, the DVT 535C is equipped with 256 MB of RAM along with 64 MB of flash memory, supporting robust data processing capabilities.
