S801T30N3S

Description: The Eaton Cutler-Hammer S801T30N3S soft starter is a reduced voltage type of soft starter from the Eaton S801 series. It comes with a special edge sensing control feature. The S801T30N3S reduced voltage soft starter comes with a Size T frame. Its operating current range runs from 95 to 304 Amps. The S801T30N3S reduced voltage soft starter can gently accelerate and decelerate 3-phase industrial motors.
Available Now
Request a quote for S801T30N3S

Description: The Eaton Cutler-Hammer S801T30N3S soft starter is a reduced voltage type of soft starter from the Eaton S801 series. It comes with a special edge sensing control feature. The S801T30N3S reduced voltage soft starter comes with a Size T frame. Its operating current range runs from 95 to 304 Amps. The S801T30N3S reduced voltage soft starter can gently accelerate and decelerate 3-phase industrial motors.

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Eaton Cutler-Hammer.

top legal disclaimer
disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the S801T30N3S.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 20 reviews

    Technical Specifications for S801T30N3S

BrandEaton Cutler-Hammer
Part NumberS801T30N3S
ManufacturerEaton
Part Number/Catalog No.S811+T30N3S
DescriptionSoft Starter
Nominal Load Voltage:208/240/380/480/575 Volts AC
Max Current:304 Amps
Control Voltage:24 VDC
Input Voltage Range:200 to 600 Volts AC
Max HP 200/208V 3PH:60 Horsepower
Output power @ 230/240V 3PH:75 Horsepower
Output power @ 460/480V 3PH:150 Horsepower
Output power @ 575/600V 3PH:200 Horsepower
Connection Type:In-Line
Internal Bypass:Yes
Overload Capacity:450% for 30 Seconds
Product TypeOpen Soft Starter
SeriesS801
Soft Starter TypeNon-combination
Amps304
OptionNo
Poles3
TypeStandard
Operating Frequency47-63 Hz
Insulating voltage (Ui)660V AC
Bypass mechanical lifespan10M
Voltage AC240 max.
Voltage DC120 max.
BrandEaton Cutler-Hammer
Part NumberS801T30N3S
ManufacturerEaton
Part Number/Catalog No.S811+T30N3S
DescriptionSoft Starter
Nominal Load Voltage:208/240/380/480/575 Volts AC
Max Current:304 Amps
Control Voltage:24 VDC
Input Voltage Range:200 to 600 Volts AC
Max HP 200/208V 3PH:60 Horsepower
Output power @ 230/240V 3PH:75 Horsepower
Output power @ 460/480V 3PH:150 Horsepower
Output power @ 575/600V 3PH:200 Horsepower
Connection Type:In-Line
Internal Bypass:Yes
Overload Capacity:450% for 30 Seconds
Product TypeOpen Soft Starter
SeriesS801
Soft Starter TypeNon-combination
Amps304
OptionNo
Poles3
TypeStandard
Operating Frequency47-63 Hz
Insulating voltage (Ui)660V AC
Bypass mechanical lifespan10M
Voltage AC240 max.
Voltage DC120 max.
s

About S801T30N3S

The S801T30N3S motor starter is a 3-pole reduced voltage motor starter made by Eaton Cutler-Hammer that is a very compact multi-functional soft starter in the Eaton Cutler-Hammer S801 industrial-based soft starter series. It is designed to accelerate and decelerate 3-phase motors. The S810 open soft starter series features programmable built-in overload protection and run bypass contactors for enhanced motor protection, and they are fitted with 6 SCR controls for protection against damage from inrush currents. The S801T30N3S motor starter has a 3-pole connector with a maximum current capacity of 304 Amps, and a 200 to 600 Volts AC acceptable input range. It has 125 Horsepower output power rating and standard ramp time range of 0.5 to 180 seconds. The S801T30N3S motor starter has an insulation voltage of 660 Volts AC, with a 30 to 100% programmable overload setting range (30 to 100% of the rated current) and an internal bypass lifespan of up to 10 minutes. The S801T30N3S motor starter offers several starting modes which are the selectable kick start, the ramp start, and the current limiting start, and also a soft stop mode for smooth motor control. It has built-in protection from overheating, stalling, jamming, phase loss, and phase reversal situations, and it has the shorted SCR detection capability. The S801T30N3S motor starter comes with a load or line side-mounted add-on lug kit for easy connections, and it also has 24 Volts DC control which enhances user and equipment safety. It has a working temperature range of -30 and 50 degrees Celsius, and it is designed for tough and rugged industrial environments. The S801T30N3S motor starter is c-UL-us, CSA, and CE certified, and it has an average shipping weight of 21.8 kilograms.

The S801+T30N3S is a soft starter device that is manufactured by Eaton Corporation. This motor starter is part of the S801+ series of reduced voltage, compact soft starters. This soft starter has an operating voltage range of 200-600 Volts AC, 47-63 Hertz and delivers an output current of 304 Amperes and output power of 60 Horsepower @ 200/208 Volts 3PH; 75 Horsepower @ 230/240 Volts 3PH; 150 Horsepower @ 460/480 Volts 3PH; 200 Horsepower @ 575/600 Volts 3PH.

The S801+T30N3S is an open-type soft starter that comes with built-in features including Bypass contactor, overload protection, adjustable ramp time and adjustable torque control. It also comes with a variety of protective features including jam and stall detection; SCR overtemperature; phase loss and imbalance; automatic and manual reset capabilities; phase reversal; shorted SCR detection; under and overvoltage detection; and undercurrent and internal diagnostics.

Available starting and stopping functions to this drive includes kick start which implements voltage ramp start and current limit start; Soft stop for application that require and compatible with extended of ramping stop. It also has embedded control functions including local control; level or edge sensing and Auto / Manual reset.

The S801+T30N3S has a ramp time range of 0.5 - 180 seconds; Soft stop time range of 0-60 seconds; Kick-start time range of 0-2 seconds and initial torque of 0-85%. It comes with embedded I/O terminals for Hardwired Start, Hardwired Stop, Jog, Overload Disable, and Fault Reset. It also has a Normally Open (N.O.) contact for internal bypass indication and a Normally Open (N.O) Fault indication relay contact.

FAQ for S801T30N3S

What are the output power ratings of the S801+T30N3S?


The S801+T30N3S has output power ratings of 60 HP @ 200/208V 3PH; 75 HP @ 230/240V 3PH; 150 HP @ 460/480V 3PH; 200 HP @ 575/600V 3PH.

What are available starting and stopping options to the S801+T30N3S?


The S801+T30N3S is capable of Kick start for implementing Voltage Ramp start and Current limit start; Soft stop for applications that require and compatible with extended of ramping stop.

What are embedded I/O signals to the S801+T30N3S?


The available I/O to the S801+T30N3S includes Hardwired Start, Hardwired Stop, Jog, Overload Disable and Fault Reset. It also has a Normally Open (N.O.) contact for internal bypass indication and a Normally Open (N.O) Fault indication relay contact.

Technical Description of S801T30N3S

The S801+T30N3S is a PowerEdge Soft starter that is manufactured by Eaton and is part of the S801+reduced voltage soft starters. It has a main input supply voltage requirement of 200-600 Volts AC, 47-63 Hertz, and 24 Volts DC for control circuit. It has applicable Motor Current motor output of 304 Amperes and output power of 60 Horsepower @ 200/208 Volts 3PH; 75 Horsepower @ 230/240 Volts 3PH; 150 Horsepower @ 460/480 Volts 3PH; 200 Horsepower @ 575/600 Volts 3PH.

Repair Services for S801T30N3S

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your S801T30N3S. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Reviews for S801T30N3S

Internal Review

"The S801+T30N3S is a reduced voltage type soft starter from Eaton Corporation. This soft-starter comes with output power ratings of 60 HP @ 200/208V 3PH; 75 HP @ 230/240V 3PH; 150 HP @ 460/480V 3PH; 200 HP @ 575/600V 3PH. Compared to any S811+ soft-starters with Digital Interface Module (DIM), the S801+T30N3S is without a DIM which makes local operation and configuration a little difficult. " -DO Supply Tech
