SVX050A1-4A1N1

Rated 4.5 with 9 reviews

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Eaton Cutler-Hammer.

top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

SVX050A1-4A1N1

Description: The SVX050A1-4A1N1 adjustable frequency drive is an Eaton Cutler-Hammer SVX 9000 series adjustable frequency drive. It is a powerful drive with a maximum output power rating of 50 Horsepower. The SVX050A1-4A1N1 adjustable frequency drive can control the speed and torque of AC-powered motors that operate in a frequency range from 50 to 60 Hertz. It has a NEMA Type 1 enclosure that can protect it from small amounts of dust but which is not waterproof and which should not be used outdoors. The SVX050A1-4A1N1 adjustable frequency drive has a nominal voltage rating of 480 Volts AC and input voltage rating of 380 to 500 Volts AC at 50 to 60 Hertz.
In Stock Ships Today
Request a quote for SVX050A1-4A1N1

Description: The SVX050A1-4A1N1 adjustable frequency drive is an Eaton Cutler-Hammer SVX 9000 series adjustable frequency drive. It is a powerful drive with a maximum output power rating of 50 Horsepower. The SVX050A1-4A1N1 adjustable frequency drive can control the speed and torque of AC-powered motors that operate in a frequency range from 50 to 60 Hertz. It has a NEMA Type 1 enclosure that can protect it from small amounts of dust but which is not waterproof and which should not be used outdoors. The SVX050A1-4A1N1 adjustable frequency drive has a nominal voltage rating of 480 Volts AC and input voltage rating of 380 to 500 Volts AC at 50 to 60 Hertz.

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for Eaton Cutler-Hammer.

top legal disclaimer
disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the SVX050A1-4A1N1.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.5 with 9 reviews

    Technical Specifications for SVX050A1-4A1N1

ManufacturerEaton Cutler-Hammer
BrandEaton Cutler-Hammer
Part Number/Catalog No.SVX050A1-4A1N1
Product TypeAdjustable Frequency Drive
Product FamilyOpen Drives
Horsepower50
EnclosureNEMA Type 1
Voltage 480V
Kepyad TypeAlphanumeric
Input Option3-phase, EMC H
Brake Chopper OptionNo Brake Chopper Circuit
Board ModificationsStandard Boards
Frame SizeFR7
Supply Frequency50/60 Hz
Inputs2 Analog, 6 Digital
Outputs1 Analog, 1 Digital, 2 Relay
ManufacturerEaton Cutler-Hammer
BrandEaton Cutler-Hammer
Part Number/Catalog No.SVX050A1-4A1N1
Product TypeAdjustable Frequency Drive
Product FamilyOpen Drives
Horsepower50
EnclosureNEMA Type 1
Voltage 480V
Kepyad TypeAlphanumeric
Input Option3-phase, EMC H
Brake Chopper OptionNo Brake Chopper Circuit
Board ModificationsStandard Boards
Frame SizeFR7
Supply Frequency50/60 Hz
Inputs2 Analog, 6 Digital
Outputs1 Analog, 1 Digital, 2 Relay
s

About SVX050A1-4A1N1

The SVX050A1-4A1N1 is an adjustable frequency drive from Cutler Hammer. This is an open drive with a horsepower rating of 50 HP. The drive comes with the AFD standard software series. It comes in a NEMA type 1 enclosure with a voltage rating of 480 volts. The input voltage range for the drive can vary from 380 to 500 volts. The SVX050A1-4A1N1 has an alphanumeric keyboard and has a 3 phase EMC Level H option. The drive does not have a chopper circuit for breaking and comes in a standard nonconformal board configuration. The SVX050A1-4A1N1 is from the SVX9000 family of drives which is made by Cutler Hammer. The drive has the following dimensions it has a height of 24.8 inches and a depth of 10.1 inches.



The SVX050A1-4A1N1 is 9.3 inches wide and it weighs 35 kilograms. The drive has excessive current protection and overvoltage protection. It also can detect under voltage conditions and earth fault conditions. There are other features like excessive temperature protection, motor overload protection, motor stall protection, and short-circuit protection. The SVX050A1-4A1N1 is made to be operated at an ambient operating temperature of -10 to 50 degrees Celsius in conditions with no frost and the relative humidity of the environment should be 0 to 95%, noncondensing. The drive is suited to be operated in an environment with the air quality conforms to the IEC 721-3-3 standards. It is certified by the IEC 61800-2 product standards and the UL 508C safety standards. It is also compliant with the EMC standards as per the EMC immunity requirements and the emissions EN 61800-3 Level H standards.



Technical Description of SVX050A1-4A1N1

The Eaton Cutler-Hammer SVX050A1-4A1N1 Adjustable Frequency Drive has 50 hp, a 480V Voltage , and a FR7 Frame Size. It also contains 8 Inputs and 4 Outputs.

Repair Services for SVX050A1-4A1N1

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your SVX050A1-4A1N1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Dimensions For SVX050A1-4A1N1

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For SVX050A1-4A1N1

Resolutions For SVX050A1-4A1N1

About

Technical Specifications for SVX050A1-4A1N1

ManufacturerEaton Cutler-Hammer
BrandEaton Cutler-Hammer
Part Number/Catalog No.SVX050A1-4A1N1
Product TypeAdjustable Frequency Drive
Product FamilyOpen Drives
Horsepower50
EnclosureNEMA Type 1
Voltage 480V
Kepyad TypeAlphanumeric
Input Option3-phase, EMC H
Brake Chopper OptionNo Brake Chopper Circuit
Board ModificationsStandard Boards
Frame SizeFR7
Supply Frequency50/60 Hz
Inputs2 Analog, 6 Digital
Outputs1 Analog, 1 Digital, 2 Relay
ManufacturerEaton Cutler-Hammer
BrandEaton Cutler-Hammer
Part Number/Catalog No.SVX050A1-4A1N1
Product TypeAdjustable Frequency Drive
Product FamilyOpen Drives
Horsepower50
EnclosureNEMA Type 1
Voltage 480V
Kepyad TypeAlphanumeric
Input Option3-phase, EMC H
Brake Chopper OptionNo Brake Chopper Circuit
Board ModificationsStandard Boards
Frame SizeFR7
Supply Frequency50/60 Hz
Inputs2 Analog, 6 Digital
Outputs1 Analog, 1 Digital, 2 Relay

About SVX050A1-4A1N1

The SVX050A1-4A1N1 is an adjustable frequency drive from Cutler Hammer. This is an open drive with a horsepower rating of 50 HP. The drive comes with the AFD standard software series. It comes in a NEMA type 1 enclosure with a voltage rating of 480 volts. The input voltage range for the drive can vary from 380 to 500 volts. The SVX050A1-4A1N1 has an alphanumeric keyboard and has a 3 phase EMC Level H option. The drive does not have a chopper circuit for breaking and comes in a standard nonconformal board configuration. The SVX050A1-4A1N1 is from the SVX9000 family of drives which is made by Cutler Hammer. The drive has the following dimensions it has a height of 24.8 inches and a depth of 10.1 inches.



The SVX050A1-4A1N1 is 9.3 inches wide and it weighs 35 kilograms. The drive has excessive current protection and overvoltage protection. It also can detect under voltage conditions and earth fault conditions. There are other features like excessive temperature protection, motor overload protection, motor stall protection, and short-circuit protection. The SVX050A1-4A1N1 is made to be operated at an ambient operating temperature of -10 to 50 degrees Celsius in conditions with no frost and the relative humidity of the environment should be 0 to 95%, noncondensing. The drive is suited to be operated in an environment with the air quality conforms to the IEC 721-3-3 standards. It is certified by the IEC 61800-2 product standards and the UL 508C safety standards. It is also compliant with the EMC standards as per the EMC immunity requirements and the emissions EN 61800-3 Level H standards.



Technical Description of SVX050A1-4A1N1

The Eaton Cutler-Hammer SVX050A1-4A1N1 Adjustable Frequency Drive has 50 hp, a 480V Voltage , and a FR7 Frame Size. It also contains 8 Inputs and 4 Outputs.
Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your SVX050A1-4A1N1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your SVX050A1-4A1N1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.
