Product image is representative; revision or series may vary. Contact us to request a specific version.
BW2150
The BW2150 circuit breaker from Eaton Cutler-Hammer is equipped to handle a current capacity of 150 Amps. It operates at 120/240 VAC and features a two-pole configuration, making it suitable for various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for BW2150
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Circuit Breaker |
| Product Line | BW Breakers |
| Part Number | BW2150 |
| Weight | 2.81 lbs (1.28 kg) |
| UPC | 786676460408 |
| Current Rating | 150 Amps |
| Interrupting Rating | 10 kAIC |
| Poles | 2 Poles |
| Voltage Rating | 120/240 VAC |
| Wire Size | #2 AWG-300 kcmil |
| Wire Type | Cu/Al |
| Use With | Type ECB Unit Enclosures |
| Connection | Plug-in |
| Certification | UL |
| Max. Relative Humidity | 80% (Non-Condensing) |
The Eaton Cutler-Hammer BW2150 is a two-pole circuit breaker designed for reliable performance in electrical systems. This unit operates at an input voltage range of 120 to 240 VAC, effectively managing a maximum current of 150 Amps. It incorporates an interrupting capacity of 10 kAIC, providing essential protection against short circuits.
To ensure compatibility with various installations, the BW2150 supports wire sizes from #2 AWG up to 300 kcmil, suitable for both copper and aluminum applications. This flexibility allows for integration into diverse electrical setups, enhancing usability in different environments. Specifically engineered for use with Type ECB unit enclosures, the BW2150 ensures seamless installation, thanks to its plug-in connection feature.
Moreover, this circuit breaker is UL certified, affirming its adherence to established safety standards. It is designed to function effectively in humid conditions, with a max relative humidity tolerance of 80% (non-condensing), making it a reliable component for various operating environments.
