Product image is representative; revision or series may vary. Contact us to request a specific version.
FDC3175
The FDC3175 is a molded case circuit breaker from Eaton Cutler-Hammer's Series C. Designed to accommodate a current capacity of 175 Amps, this device operates effectively within a voltage range of 600 VAC for alternating current and 250 VDC for direct current.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for FDC3175
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | FDC3175 |
| UPC | 786679019603 |
| Terminals | Load Side Lugs Only |
| Amperage | 175 A |
| Voltage (DC) | 250 VDC |
| Connection Type | Load Side |
| Voltage (AC) | 600 VAC |
| Poles | 3 Poles |
| Frequency | 50–60 Hz |
| Approval | UL Listed |
| Phase | 3 Phase |
| Protection | Overcurrent |
| Trip Type | Thermal Magnetic |
The Eaton Cutler-Hammer FDC3175 circuit breaker is part of the Series C line and functions as a molded case circuit breaker. It is specifically designed for high-performance applications, with a significant amperage rating of 175 A that allows efficient management of electrical loads.
This device is capable of handling voltages of up to 600 VAC for AC applications, along with supporting 250 VDC for DC usage, making it highly versatile in various electrical settings. The FDC3175 circuit breaker has three poles, making it suitable for three-phase systems, ensuring balanced load distribution.
Operating effectively under a frequency range of 50 to 60 Hz, the breaker utilizes a thermal magnetic trip type, which provides reliable protection against overcurrent. This feature is crucial for safeguarding equipment from potential damage due to overload conditions. Connections are facilitated exclusively through load side lugs, promoting secure attachment within existing electrical setups.
In terms of compliance, the FDC3175 has received UL Listing, assuring users of its safety and reliability in the field. Overall, this circuit breaker offers robust protection capabilities for various applications, ensuring efficient and safe electrical management.
