Product image is representative; revision or series may vary. Contact us to request a specific version.
GHB2030
The Eaton Cutler-Hammer GHB2030 is a molded case circuit breaker designed for versatile electrical applications. With a rated current of 30 A and voltage capabilities of 480Y/277 VAC and 125/250 VDC, this circuit breaker is suitable for various uses in both AC and DC environments.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for GHB2030
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | GHB2030 |
| Weight | 1.13 lbs (0.51 kg) |
| UPC | 786679911211 |
| Rated Current | 30 A |
| Rated Voltage (AC) | 480Y/277 VAC |
| Rated Voltage (DC) | 125/250 VDC |
| Frame Size | G Frame |
| Min. Frequency | 50 Hz |
| Max. Frequency | 60 Hz |
| Number of Poles | 2 Poles |
| Interrupt Rating at 480Y/277 VAC | 14 KAIC |
| Interrupt Rating at 240 VAC | 65 KAIC |
| Installation Altitude | 1000 MSL |
The GHB2030 from Eaton Cutler-Hammer falls under the Series C Circuit Breakers and serves as a molded case circuit breaker. It supports a rated current of 30 A, featuring both AC and DC voltage specifications. For alternating current, it operates at 480Y/277 VAC, while for direct current, it can handle voltages of 125/250 VDC.
Designed for frequencies between 50 Hz and 60 Hz, the GHB2030 is configured with a G frame size and accommodates two poles. This breaker effectively manages electrical faults, with an interrupt rating of 14 KAIC at 480Y/277 VAC. At a lower voltage of 240 VAC, it has a higher interrupt capacity of 65 KAIC, ensuring safety during overcurrent conditions.
For installations, the maximum altitude without derating is specified at 1000 meters above sea level, making it a reliable choice for various industrial environments. The product is identified by UPC 786679911211, further affirming its recognized qualities within the market.
