GHB3100
The Eaton Cutler-Hammer GHB3100 circuit breaker is a compact molded case type, specifically designed for efficient load management. With a robust amperage rating of 100 Amps, it operates effectively at voltage ratings of 480Y/277 volts AC and 125/250 volts DC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for GHB3100
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded case circuit breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | GHB3100 |
| Weight | 1.75 lbs (0.79 kg) |
| UPC | 786679911334 |
| Trip Type | T186 |
| Circuit Breaker Type | GHB |
| Circuit Breaker Frame Type | Complete breaker |
| Amperage Rating | 100 Amps |
| Voltage Rating | 480Y/277 volts AC, 125/250 V DC |
| Frequency Rating | 50/60 Hertz |
| Interrupt Rating | 14 kAIC at 480Y/277 V AC; 65 kAIC at 240 V AC |
| Number of Poles | Three-pole |
| Wire Range | AWG #10 – 1/0 (Aluminum or Copper) |
| Certifications | UL Listed |
The GHB3100 from Eaton Cutler-Hammer is a molded case circuit breaker that provides reliable protection in various electrical systems. This unit boasts an amperage rating of 100 Amps, ensuring it adequately handles substantial loads. It operates within a versatile voltage range, supporting 480Y/277 volts AC and 125/250 volts DC.
The breaker type is GHB, and it features a trip mechanism designated as T186, which enhances its ability to disconnect in case of overloads. Constructed as a complete breaker, it offers dependable performance. The interrupt ratings of this breaker include a 14 kAIC maximum at 480Y/277 V AC and 65 kAIC at 240 V AC, indicating its capability to manage fault currents effectively.
This three-pole design allows for flexible wiring configurations, accommodating inputs from either aluminum or copper wires within the AWG #10 to 1/0 range. Additionally, this circuit breaker is UL Listed, meeting essential safety and performance standards. The specifications make the GHB3100 ideal for a variety of applications requiring robust protection against electrical overloads.
