Product image is representative; revision or series may vary. Contact us to request a specific version.
HMCP250G5C
The HMCP250G5C from Eaton Cutler-Hammer is a molded case circuit breaker designed for motor protection. It accommodates a rated current of 250 A and operates effectively at voltages of up to 600 VAC or 250 VDC, fitting well into various industrial setups.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HMCP250G5C
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker Accessory Motor Protection |
| Product Line | Series C Circuit Breakers |
| Part Number | HMCP250G5C |
| Weight | 12.50 lbs (5.67 kg) |
| UPC | 786679151037 |
| Rated Current | 250 A |
| Frame Type | J-K frame |
| Rated Voltage AC | 600 VAC |
| Rated Voltage DC | 250 VDC |
| Terminal Type | Line and Load |
| Terminal Material | Non-Aluminum |
| Number of Poles | 3 Poles |
| Storage Humidity | 80% (non-Condensing) |
| Operating Humidity | 80% (non-Condensing) |
| Installation Altitude | 1000 MSL |
Eaton Cutler-Hammer presents the HMCP250G5C, a molded case circuit breaker accessory specifically tailored for motor protection. This breaker can handle a rated current of 250 A, making it suitable for substantial electrical loads. It operates efficiently with an AC voltage rating of 600 VAC and can also manage a DC voltage of 250 VDC, providing flexibility for diverse applications.
The HMCP250G5C is designed with a J-K frame type and is equipped with three poles, ensuring dependable performance in trip situations. For connection options, the breaker features terminals suited for both line and load, made from non-aluminum materials to enhance reliability.
Operationally, it remains stable within environments maintaining humidity levels of up to 80%, both during use and in storage. Additionally, the design allows installation at altitudes of up to 1000 meters above sea level. Overall, the HMCP250G5C serves as a robust choice for enhancing motor protection in industrial applications.
