Product image is representative; revision or series may vary. Contact us to request a specific version.
HMCP400R5C
The HMCP400R5C is a molded case circuit breaker from Eaton Cutler-Hammer's Series C. It operates as a 3-pole, 3-phase device with a high ampere rating of 400 A, ensuring reliable performance in various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HMCP400R5C
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | HMCP400R5C |
| Weight | 15.00 lbs (6.80 kg) |
| UPC | 786679342602 |
| Poles | 3 Pole |
| Phase | 3-Phase |
| Connection Type | Feed-Thru |
| Trip Unit Type | Magnetic Only |
| Protection Type | Magnetic |
| Mounting Type | Panel/Busway |
| Ampere Rating | 400 A |
| Terminals | Line & Load Lugs |
| Interrupt Rating at 480 V | 35 kAIC |
| Control Type | Instantaneous |
| Voltage Rating | 600 VAC/250 VDC |
| Trip Functions | Instantaneous Only |
The Eaton Cutler-Hammer HMCP400R5C is a robust molded case circuit breaker designed for industrial applications. It features a 3-pole configuration suitable for 3-phase systems. With a substantial ampere rating of 400 A, this breaker provides reliable protection for electrical circuits. The voltage rating stands at 600 VAC for alternating current and 250 VDC for direct current. The breaker has a high interrupt rating of 35 kAIC at 480 volts, ensuring effective performance under fault conditions.
This circuit breaker is equipped with a feed-thru connection type, which allows for straightforward integration into electrical panels. It supports line and load lug terminals for efficient connection setups. The mounting options include easy panel or busway installation, making it versatile for various environments. The HMCP400R5C trip unit employs magnetic-only trip technology, focusing on instantaneous trip functions. This design ensures rapid response to electrical faults, safeguarding connected equipment from potential damage.
