Product image is representative; revision or series may vary. Contact us to request a specific version.
HMCP600L6W
The HMCP600L6W motor circuit protector from Eaton Cutler-Hammer is designed to ensure excellent protection for motors within its operational range. Rated at 600 A and featuring a trip type that operates magnetically, this unit is capable of handling three poles effectively.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for HMCP600L6W
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Motor circuit protector |
| Product Line | Series C Circuit Breakers |
| Part Number | HMCP600L6W |
| Weight | 20.00 lbs (9.07 kg) |
| UPC | 786679281369 |
| Frame Size | J-K |
| Max DC Voltage | 250 VDC |
| Max AC Voltage | 600 VAC |
| Rated Current | 600 A |
| Pole Count | 3 Poles |
| Magnetic Trip Range | 1800-6000 A |
| Interrupting Rating | 100 kAIC @ 480 VAC |
| Trip Type | Magnetic-only |
| Mounting Style | Panel |
| Terminal Options | Lugs not supplied |
| Enclosure Protection | NEMA 6 |
| Contact Mechanism | High-speed blow-open |
The Eaton Cutler-Hammer part HMCP600L6W is a motor circuit protector specifically engineered for high-performance applications. Operating within a frame size categorized as J-K, this device handles a maximum direct current of 250 VDC alongside an alternating current of up to 600 VAC. Designed for robustness, the HMCP600L6W is rated for 600 A and is capable of sustaining up to three poles for effective motor protection.
The magnetic trip mechanism, which operates within a range of 1800 to 6000 A, ensures reliable operation, particularly in demanding conditions. An interrupting rating of 100 kAIC at 480 VAC signifies its ability to protect circuits against potential faults. Designed with NEMA 6 enclosure standards, the device is resistant to dust and water, which enhances its longevity and reliability in harsh environments.
Installation is uncomplicated with panel mounting, although note that lugs are not provided. This motor circuit protector features a high-speed blow-open contact mechanism, which enhances safety during fault conditions by providing rapid disconnection of the circuit. The HMCP600L6W is a crucial component for automation systems requiring dependable motor circuit protection.
